Auto Far Infrared Sensor Stainless Steel Air Shower Room For Seafood Workshop

Certification
China KeLing Purification Technology Company certification
China KeLing Purification Technology Company certification
Customer Reviews
Keling had successfully supplied us following products on 25 Oct.2017 against PO NO.M170807; Their supplied Air Filters have been working satisfactorily since installation.We are satisfied with their products.

—— SIMPOR PHARMA

Since we do coopertae with them, they always offer good quality and keep the delivery on time to us, we do appreicated for their kind support !

—— Nasir

This is to certify that we bought U type air shower tunnel, Air Shower and HEPA filter, Secondary air filter ,perfilter for our project from KeLing Purification Technology Co. Ltd, 3C01 Tian Feng Commerce Square, Mid Building, No. 133, Baiyun AV, Baiyun Disctrict , Guangzhou , GuangDong, China against Contract No: 2014/4119005942 in October 22, 201

—— IATEC,Argentina

Product arrived faster than expected and they sent something special in addition to what I ordered. Nice people and fast service!

—— Mohammed Saad

I'm Online Chat Now

Auto Far Infrared Sensor Stainless Steel Air Shower Room For Seafood Workshop

Auto Far Infrared Sensor Stainless Steel Air Shower Room For Seafood Workshop
Auto Far Infrared Sensor Stainless Steel Air Shower Room For Seafood Workshop Auto Far Infrared Sensor Stainless Steel Air Shower Room For Seafood Workshop

Large Image :  Auto Far Infrared Sensor Stainless Steel Air Shower Room For Seafood Workshop

Product Details:
Place of Origin: China
Brand Name: K-LING
Certification: CE
Model Number: KEL-AS2000P-2
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: NEGOATION
Packaging Details: PLOWOOD PACKING
Delivery Time: 8 WORKING DAYS
Payment Terms: Ex works/FOB/CIF/ CNF
Supply Ability: 100UNITS/MONTH
Detailed Product Description
Other Name: Decontamination Room Cabinet Size: 2000X2000X2180mm
Working Size: 1500x1930x1910mm Control System: PLC Control System
Locker: Electric Inter Locker Power: 380V / 50HZ
High Light:

clean room air shower

,

air shower room

Auto Far Infrared Sensor Stainless Steel Air Shower Room For Seafood Workshop





Quickly detail:



External Size: 2000x2000x2180mm

Internal size : 1500x1930x1910mm

Four persons with three side blowing

Disposable prefilter
SS air nozzles
Energy Efficient
Microprocessor controller
High velocity shower jets
Emergency stop buttons





 Introduce:



  As the filtration equipment through the action of high strength air flow, the double person air shower room is often used in conjunction with clean room.It can remove the impurity such as dust on the working staff before they go into the clean room. Each side of our product has six nozzles with a wide distribution range. With the mouth diameter of 30mm, the nozzle can spray out the air quickly
and the air shower area can be up to 1500×1900×1910mm. The air shower time can be adjusted in the range of 0 to 99s. Thus, the air shower effect can be assured to be the best level, which guarantees the cleanliness of the clean room completely.



keling  is an experienced stainless steel air shower room manufacturer in China.We also supply double person air shower room, stainless steel clean room pass box, double door clean cabinet, air curtain, and much more.





Specification :



Main body: 1.2mm Carbon Steel with anti-sepsis powder coating, milk white colour
a:       Inner Wall: 1.0mm Stainless Steel 304
b:       Door: Carbon Steel with anti-sepsis powder coating hair line 800x1910,
          Two window     (up & down, 5mm tempered glass)
c:       Door Closer: Brand GMT
d:       Blower: Air Shower Room use blower, power 0.75kw
e:       HEPA Filter: mini-pleats HEPA filter , filter efficiency 99.995%@0.3um
f:       Nozzle: stainless steel 201, diameter of the wind out 25mm
g:       Interlock: Brand K-LING
h:       Auto Air Shower Control: Mircoprocessor, or  PLC, LCD, one set
i:       Air Outlet: SS 304 with punching
j:      Base Floor: 1.0mm SS 304 with enhancing process
k:      Lighting: Fluorescence light 2x20W




Parameter :



KEL-AS2000P-2 Series

Model

KEL-AS2000P-2

External size(mm) (WXDXH)

2000x2000x2180

Work zone (mm)(WXDXH)

1500x1930x1910

Persons per cycle

4 -8person

Air shower Duration

                        Factory set at 12 second (adjustable)

Material

         Steel with white color epoxy power-coated or Stainless steel

Fan consumption

0.75KWX4sets

Air flow of fan(m3/h)

                                                  1300m3/h

Fan run (r/min)

                                                2800r/min

Nozzle in stain less steel

                                                      40pcs

Wind speed(m/s)

                                                  > 22-27m/s

Noise level(dB)

                                                      <62dB

LED Fluorescent Lamp

                                                     20wx2





HEPA Filter

Size(mm)

                                               630X630X69mm

Efficiency

                                          99.99%@0.3um

Air velocity

                                                 1000(m3/h)

Resistance

                                                    <220pa





Pre-filter

Size(mm)

                                                785x385x21

Efficiency

                                               75% @ 5um

Resistance

                                                      <30 Pa

Electrical

Power supply

                                                    380v/50Hz





































































Controls:



- Shower operation controlled by solid sate LCD timer, with tamper-proof closure to ensure selected setting is maintained.
- Emergency "off" button with audible alarm installed inside shower. Built-in relays from motors, locks and timers.
Sequential operation initiated by sensor & door magnetic switch.





Electrical & Power Requirements:



- All electrical components UL Approved. 230V or 460V, 3 Ph.
- Junction box on top for customer power supply.
- Control circuitry 12V DC & 24V AC


Motor/Blower Assembly:



- High efficiency motors to reduce electrical load.

- Motors thermally protected & self-lubricating.
- Motors/Blowers are selected to maintain constant required airflow rate up to twice the initial static pressure.
Filter/Blower housing has simple plug-in connector.

Lighting -Recessed 2 pin fluorescent lighting. 60 ft. candles.




Factory test:



All of equipment is individually factory tested for safety and performance in accordance with international Standards. Each unit is shipped with a documentation outlining the tests undertaken and the units individual results for each unit.

Factory test include:

--functional test and visual inspection

--electrical safety tests

--air velocity testing

--purification rank test (if need)



Consumable parts illustration:



1: Pre-filter: each one should be replacement in each 6 month, but it can refresh no more three times.



2: HEPA filter: each one should be replacement in each half and one years.



Warranty:



Our equipment is warranty for 1 year excluding consumable parts and accessories.

All equipment is shipped with a comprehensive use’s manual complete with a report documenting all test procedures.

Additional IO/OQ/GMP document is available upon request.

Contact our sales representative for specific warranty details or document request.





Payment Term:



T/T in advance, 30% before place the order, 70% when you see copy BL

Or 30% T/T in advance before place the order, 70% LC at sight.
