Accessories Pass Box With Hinges And UV Light Ultimate Solution For Clean Room

Product Description:

A static pass box designed for cleanroom environments, the Cleanroom Pass Box offers a convenient solution for transferring materials between controlled areas while minimizing contamination risks. With an internal size of 500*500*500mm, this pass box provides ample space for various items to be passed through.

Equipped with supported options for landing and lifting, the Cleanroom Pass Box allows for flexible handling of materials, catering to different user preferences and requirements. Whether you prefer a customized landing and lifting mechanism or opt for the default settings, this pass box ensures smooth transfer operations.

Technical Parameters:

Power Supply	220V/50Hz
Products Name	Pass Box
UV Light	Yes
Surface Treatment	Polished
Port	Shanghai, Shenzhen, Ningbo
Feature	Critical Cleaning / Residue Free
Weight	80kg
Landing And Lifting	Supported Options Custom
Process	Laser, punching, bending, paint etc
Internal Work Zone	600*600*600mm

When customizing the transfer window, the following details are required to ensure that the transfer window can meet the specific use needs and environmental requirements:
1. Dimensions and specifications
Size: Specify the length, width and height of the transfer window to ensure that it can be adapted to the installation position.
Installation method: Confirm whether the transfer window is embedded in the wall or the floor installation.
Non-standard customization: If there is a special size requirement, please specify in advance.
2. Interlock function
Interlock type: Select mechanical interlock or electronic interlock. Electronic interlocking enables more advanced control functions.
Interlock mechanism: ensure that both sides of the door can not be opened at the same time to prevent air cross-pollution.
3. Material and surface treatment
Housing material: usually stainless steel or aluminum alloy, to ensure corrosion resistance and easy cleaning.
Surface coating: anti-static polyester resin and other coatings can be selected to prevent electrostatic adsorption.
4. Disinfection and purification function
Ultraviolet light: Equipped with ultraviolet light to disinfect the surface of the item, the disinfection time should be specified (usually 30 minutes).
High Efficiency Filter (HEPA) : For higher cleanliness, a HEPA filter is available.
Air shower function: For high cleanliness requirements, you can choose air shower transfer window.
5. Additional features
Walkie-talkie: equipped with walkie-talkie to facilitate communication between personnel on both sides of the transfer window.
Intelligent control: If remote control or identification function is required, intelligent control system can be selected.
6. Use the environment
Cleanliness level: According to the cleanliness level requirements of the use environment (such as class A, Class B, etc.), select the appropriate transfer window configuration.
Environmental conditions: Confirm that the transfer window is suitable for a specific environment, such as low temperature, high temperature, high humidity, etc.
7. Installation and maintenance
Installation position: Select a position that is easy to operate and does not affect the clean air flow organization.
Sealing treatment: Ensure that the transmission window and the wall are well sealed to prevent air leakage.
Maintenance requirements: Regular cleaning and maintenance, including checking UV lamps, replacing filters, etc.
8. Security and compliance
GMP compliance: Ensure that the transfer window complies with relevant industry specifications (e.g. GMP).
Safety protection: Equipped with safety protection facilities, such as guardrail, if necessary
