Horizontal HEPA Air Duct Filter Box , Hepa Filter System Class100

Certification
China KeLing Purification Technology Company certification
China KeLing Purification Technology Company certification
Customer Reviews
Keling had successfully supplied us following products on 25 Oct.2017 against PO NO.M170807; Their supplied Air Filters have been working satisfactorily since installation.We are satisfied with their products.

—— SIMPOR PHARMA

Since we do coopertae with them, they always offer good quality and keep the delivery on time to us, we do appreicated for their kind support !

—— Nasir

This is to certify that we bought U type air shower tunnel, Air Shower and HEPA filter, Secondary air filter ,perfilter for our project from KeLing Purification Technology Co. Ltd, 3C01 Tian Feng Commerce Square, Mid Building, No. 133, Baiyun AV, Baiyun Disctrict , Guangzhou , GuangDong, China against Contract No: 2014/4119005942 in October 22, 201

—— IATEC,Argentina

Product arrived faster than expected and they sent something special in addition to what I ordered. Nice people and fast service!

—— Mohammed Saad

I'm Online Chat Now

Horizontal HEPA Air Duct Filter Box , Hepa Filter System Class100

Horizontal HEPA Air Duct Filter Box , Hepa Filter System Class100
Horizontal HEPA Air Duct Filter Box , Hepa Filter System Class100

Large Image :  Horizontal HEPA Air Duct Filter Box , Hepa Filter System Class100

Product Details:
Place of Origin: CHINA
Brand Name: K-LING
Certification: CE,
Model Number: KEL-610
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: NEGOATION
Packaging Details: PLOWOOD PACKING
Delivery Time: 8 WORKING DAYS
Payment Terms: Ex works/FOB/CIF/ CNF
Supply Ability: 3000SetS/month
Detailed Product Description
High Light:

hepa filter unit

,

air filter box

Horizontal HEPA Air Duct Filter Box , Hepa Filter System Class100


Quicky detail

Internal Size: 680x680x380mm
Purification rank: Class100-10000
HEPA filter efficiency:99.99%- 99.999%@0.3um
HEPA filter size : 610x610x96mm
Air speed :0.3-0.6m/s
Material : steel with power coated.


Parameter :



Model

Install size

Filter size

Flange size

Air flow

Tube on top/side

(BXAXH)mm

(H13)

(mm)

M3/h

KEL-320

390x390x380

320X320X96

200x200/Ø300

 500

KEL-484

554x554x380

484X484X96

200x320/Ø300

1000

KEL-610

680x680x380

610X610X96

200x400/Ø300

1500

KEL-915

680x985x380

610X915X96

200x500/Ø300

2000

KEL-1220

680x1290x380

610x1220x96

300x500/Ø300

3000

Customized design is available.


Introduction:


HEPA filter boxe made by galvanised sheet painted electrostatically in color white RAL9010. In the box there is a base for the HEPA filter. In the four corners there are clamps for the fixing of the filter. There is roynd spigot for the connection with the supply air duct. As optional can be installed, Installation for the pressure drop measurement,Damper in the air inlet spigot manually adjusted.
Leaking test certificate



Applications: conventional clean room construction and HVAC air filter system.



Operating features:

1: The cabinet material is steel with power coated and the anti-static process.
2: The structure is impact and has a good capability for airproofing. Its entrance has two kinds: quadrate and rotundity.
3: the clean room may be limited by the building's height or need the compact design,
 You can choose the integrative HEPA/ULPA Unit



Factory test:

All of equipment is individually factory tested for safety and performance in accordance with international Standards. Each unit is shipped with a documentation outlining the tests undertaken and the units individual results for each unit.



Factory test include:

-- functional test and visual inspection
-- electrical safety tests
-- air velocity testing
-- purification rank test (if need)


Warranty:

Our equipment is warranty for 1 year excluding consumable parts and accessories.
All equipment is shipped with a comprehensive use’s manual complete with a report documenting all test procedures.
Additional IO/OQ/GMP document is available upon request.
Contact our sales representative for specific warranty details or document request.


Consumable parts illustration:

1: Pre-filter: each one should be replacement in each 6 month, but it can refresh no more three times.

2: HEPA filter: each one should be replacement in each half and one years.


Why you choose K-LING Company ?

Professional sales:

• We value every inquiry that you sent to us, ensure quick competitive offer.
• We cooperate with customer to bid tenders. Provide all necessory docuement.
• We are a sales team, with all techinical support from engineer team


Punctual delivery time:

• Production / inspection report provide before shipment
• Shipping notice or insurance for you when your goods is shipped.
After sales service:
• We respect your feed back after receive the goods.
• We provide one year warranty after goods arrive.
• We promise all spare parts available in lifetime use.
• We care of your complain within 48hours.


Payment Term:

 T/T in advance, 30% before place the order, 70% when you see copy BL
Or 30% T/T in advance before place the order, 70% LC at sight.
