Other Name: | Dynamic Pass Box | Internal Size: | 600X970X600mm |
---|---|---|---|
External Size: | 980x970x2250mm | Material: | Inside Is SUS304 Outside Is Steel With Power Coated |
Auto Conveyor: | Automatic PVC Conveyor Line | Control System: | PLC Control System |
Highlight: | modular clean rooms,clean room cabinets |
PLC Control System Air Shower Pass Box With Auto Roll Conveyor Line 380V / 50HZ
Quickly detail:
Extenal size : 980x970x2250mm
Internal Size: 600x970x600mm
Filtration step : 2 step
HEPA filter efficiency: 99.999%@0.3um
Control system: PLC Control system
Blower way: three size blowing
Air speed :>25m/s
Power: 380V/50HZ
Introduction:
Built-in air shower significantly reduces surface contamination on materials entering or exiting the controlled environment, material entering or exiting the controlled environment by high velocity HEPA filtered air jets with velocities of 20-25m/s. contaminated air is then drawn through the base within the unit, filtered and recirculated.
Applications:
It is widely used in the clean environment, such as micro-electronic, laboratory, national defense, precise instrument, bio-pharmaceuticals, photo-electric, aseptic packaging field and so on.
Technical Parameter:
MODEL |
Air shower pass box with auto roll conveyor line |
External size(mm) (WXDXH) |
980X970X2250 mm |
Internal size (mm) (WXDXH) |
600X970X600mm |
Interlocker |
electronic interocker |
Air way |
three side air blowking |
Pre-filter (mm) |
560x275x17 |
HEPA Filter(mm) |
630x630x69 |
Air flow (m/s) |
1200m3/h |
Fan power |
380V/50HZ 600w (1set) |
Noise |
<75 |
HEPA Filter |
99.995% @0.3um |
UV lamp |
1 pcs |
Material
|
1:Entirety Sus201/304 (T=1.0/1.2mm) 2:External is steel with power coated, Internal is SUS304(T=1.0/1.2mm) 3: External is steel with power coated. Internal is SUS201 (T=1.0/1.2mm) |
Customer’s design is available.
Control Programe :
1: Exit is automatic slid door(up/down), entrance door is normally manual door
2: after the goods entrance the cabinet closed the entrance door,
the air clean system will be working 15s.meanwhile the two door interlock.
3:15s later, the exit door will be open automatic, and the conveyor system will be move on. When the goods
pass the photo-electrics sensor that will be give single to the back door for close. (the part1 and part 2
should be together start and stop)
4: Three side with blow. 1 Sets ion anti-static device.
5: Emergency button help you out of suddenly trouble
Part1: Technology Illustration:
1: Major Structure and frame: Aluminum profile (50x50mm)
2: Belt: Anti-static PVC belt green color
3: Height: 700-1000mm adjustable
4: Motor: 0.4kw 380V/ 50HZ.
5: Speed: 1-15m/min (adjustable)
Part2: Technology Illustration:
1: Major Structure: steel with power coated plated
2: Frame: steel with power coated square cube. 40mmx40mmx1.5T
3: Belt: Anti-static PVC belt green color
4: Motor: 380V/50HZ.
5: Speed: 1-15m/min adjustable
Warranty:
Our equipment is warranty for 1 year excluding consumable parts and accessories.
All equipment is shipped with a comprehensive use’s manual complete with a report documenting all test procedures.
Additional IO/OQ/GMP document is available upon request.
Contact our sales representative for specific warranty details or document request.
Consumable parts illustration:
1: Pre-filter: each one should be replacement in each 6 month, but it can refresh no more three times.
2: HEPA filter: each one should be replacement in each half and one years.
