| Material: | Stainless Steel | Name: | Clean Room Pass Box |
|---|---|---|---|
| Type: | Dynamic Pass Box | Air Speed: | 0.3m/s |
| Warranty: | 1 Year | Filter: | Hepa Filter |
| High Light: | Lab Electronic Dynamic Pass Box,SUS 304 Dynamic Pass Box,316L Cleanroom Pass Box |
||
Lab Electronic Dynamic Pass Box With Testing Port And SUS 304/316L Stainless Steel
Quick Detail
Model: KEL-DPB-300Outer
Size(mm):500(W)*360(D)*830(H)
Inner Size(mm): 300(W)*300(D)*300(H)
Filters: Pre-Filter, HEPA Filter 99.99%@0.3umHigh Efficiency
Differential Pressure Gauge
UV Light
Power supply: 220V,50Hz
Installation: It doesn't need installation.
Features:
Tempered glass doors provide a clear view of the internal chamber.
The main body of the pass box is constructed of SUS 304/316L stainless steel.
Variety of accessories and dimensions.
Containment System:
Manufactured for the most demanding controlled environment applications.
Mechanical or electronic interlock is reliable, maintenance-free, fail safe and maintains Clean Room integrity by preventing both doors from being opened at the same time.
Excellent to avoid cross contamination.
All components are designed for maximum chemical resistance and enhanced durability for a long service life.
The internal side walls of the pass box are constructed from a single piece of stainless steel, with coved corners for easy cleaning.
Tempered glass doors provide visibility into the interior.
Frameless construction is easy to clean with no joints for contaminants to accumulate.
Stainless steel frame, and double-deck 5mm thick tempered glass door.
Parameter
| Body material (external) | ①: 1.2mm cold rolled steel plate (Electrostatic paint)②: 304/316# stainless steel (mirror/sanding) |
| Working material(Internal) | 304/316# stainless steel |
| Door | 5mm tempered glass |
| Interlocking function | Mechanical interlocking/Electronic interlocking |
| Optional accessories | 1. Intercom device2. Ultraviolet germicidal lamp3. Roller device |
| Specifications | Static Pass Box | Dynamic Pass Box |
| Working Dimensions | 400x400x400, 500x500x500, 600x600x600 or Customized | |
| Material | SS304, SUS304, SS Sheet, Thick.=1.0, 1.2mm | |
| Glass | Double Tempered Glass, Thick.=5mm | |
| Hinge | Mechanic/Electronic Interlocker System | |
| Power Supply | 220V, 50HZ | |
| UV Light | YES | YES |
| Air Velocity | N/A | 0.3m/s-0.6m/s |
| HEPA | N/A | EU 14 grade with an efficiency of 99.995% for 0.3 mic. (GEL TYPE) |
| Prefilter | N/A | EU 4 grade with an efficiency of 90% for 10 mic. |
| Accessories | N/A | PAO test port Of HEPA, High Efficiency Differential Pressure Gauge |
