Workshop Class 1000 Air Shower Tunnel / Channels , Pharmaceutical Clean Room

Workshop Class 1000 Air Shower Tunnel / Channels , Pharmaceutical Clean Room
Workshop Class 1000 Air Shower Tunnel / Channels , Pharmaceutical Clean Room Workshop Class 1000 Air Shower Tunnel / Channels , Pharmaceutical Clean Room

Large Image :  Workshop Class 1000 Air Shower Tunnel / Channels , Pharmaceutical Clean Room

Product Details:
Place of Origin: CHINA
Brand Name: K-LING
Certification: CE
Model Number: KEL-AS2000T-3 SERISE
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: NEGOATION
Packaging Details: PLOWOOD PACKING
Delivery Time: 15 WORKING DAYS AFTER DEPOSIT
Payment Terms: T/T, LC AT SIGHT
Supply Ability: 50UNITS/MONTH
Detailed Product Description
Air Shower Type: Z Type Air Shower Tunnel Control System: Microelectronics Control System
Function: Infrared Automatic Induction External Material: Steel With Power Painting
Internal Material: SUS304 Power Supply: 380V/50HZ
Product Name: Cleanroom Air Sshower Applcation: Pharmaceutical Clean Room
Cleanroom: General Cleanroom Air Shower Time: 0-99s Adjustable
High Light:

electronics clean room

,

biological clean room

Workshop Class 1000 Air Shower Tunnel / Channels , Pharmaceutical Clean Room





Quicky detail



External Size: 2000x3000x2300mm

Internal size : 1500X2930X2000 mm

Purification rank: Class1000

HEPA filter efficiency: 99.999%@0.3um

SUS nozzle: 60pcs

Blower way: three size blower

Air speed :>25m/s

Power: 380V/50HZ





Applications: it can keep pharmaceutical, semiconductor, micro-electronics production and lab animal breeding areas clean and also minimize egress of hazardous substances and allergens from the controlled environment.



Introduced :



Completely self-contained, pre-wired, fully equipped Air Shower/Tunnel systems help solve decontamination problems
HEPA filter/blower modules (rated 99.97% efficient @ 0.3 micron particles) wash personnel with
Class 100 air to dislodge and remove particles
Solid-state microprocessor panel provides programmable control over access door operation
Interlocking doors minimize contamination, release automatically in the event of power failure
Fluorescent lighting is housed in the ceiling for minimal turbulence
Available in white epoxy-finished CR steel, stainless steel, or combination
of CR steel and stainless steel to meet various cleanroom requirements
Variety of sizes and door configurations
Economical to operate, easy to maintain
Modern knock-down design



operating features :



1 : Microelectronic control system with LED display for the shower time.

2 :  Special ultrathin blowing tube housing and fan, match with rotatable

     embedded stainless steel nozzle, greatly increased the space utilization

      and blowing tube effect

3 :  Built-in many sets of operating procedures, can be convenient and flexible call.
     Intelligent man-machine dialogue interface makes operation chain, such as real-time
     monitoring state.
4: Standard of the modular design, make field assembly faster and more convenient maintenance.





                                  KEL-AS2000T-3  Air Shower Tunnel

MODEL

KEL-AS2000T-3

External size (mm)

(WXDXH)

2000x3000x2300mm

Work zone (mm)

(WXDXH)

1500x2930x2000mm

Persons per cycle

 3 pallets cargo

Air shower Duration

Factory set at 12 second (adjustable)

 Air shower direction

Three side with blowing

Material

(Option)

1: Entirety Sus304.

2: Entirety sus201.

3: External is steel with power coated, Internal is SUS304.

4: External is steel with power coated. Internal is SUS201.

Control system

1: Microelectronics control system with LED display for the shower time.

2: The shower time from 0-99second. (Adjustable).

3: Infrared ray inductor for inside personal shower automatic.

4: Human voice prompt system.

5: with CE remark

The power of Fan

380V/50HZ/750W  (3 set)

Air flow of fan(m3/h)

   1300m3/h

Fan run (r/min)

2800r/min

Wind speed(m/s)

 23-29m/s

Noise level(dB)

<62dB

LED Fluorescent Lamp

20wx3



HEPA Filter

Size(mm)

630X630X96mm

Efficiency

99.99%@0.3um

Air velocity

1000(m3/h)

Initial resistance(pa)

    <220pa



Pre-filter

Size(mm)

  775x380x17

Efficiency

     75% @ 0.5um

Resistance(pa)

    <30 Pa

Electrical

Power supply

   380v/50Hz

   Net power(kw)

     0.75X3kw

Customer’s design is available.





Factory test:



All of equipment is individually factory tested for safety and performance

in accordance with international Standards. Each unit is shipped with a documentation outlining the tests undertaken and the units individual results for each unit.

Factory test include:

-- functional test and visual inspection

-- electrical safety tests

-- air velocity testing

-- purification rank test (if need)





Warranty:



Our equipment is warranty for 1 year excluding consumable parts and accessories.

All equipment is shipped with a comprehensive use’s manual complete with a report documenting all test procedures.

Additional IO/OQ/GMP document is available upon request.

Contact our sales representative for specific warranty details or document request.





Consumable parts illustration:



1: Pre-filter: each one should be replacement in each 6 month, but it can refresh no more three times.



2: HEPA filter: each one should be replacement in each half and one years.



Why you choose K-LING Company ?



Professional sales:

• We value every inquiry that you sent to us, ensure quick competitive offer.

• We cooperate with customer to bid tenders. Provide all necessory docuement.

• We are a sales team, with all techinical support from engineer team





Punctual delivery time:



• Production / inspection report provide before shipment

• Shipping notice or insurance for you when your goods is shipped.

After sales service:

• We respect your feed back after receive the goods.

• We provide one year warranty after goods arrive.

• We promise all spare parts available in lifetime use.

• We care of your complain within 48hours.





Payment Term:



 T/T in advance, 30% before place the order, 70% when you see copy BL

Or 30% T/T in advance before place the order, 70% LC at sight.
