Stainless Steel Pharma Dispensing Booth Laminar Air Flow CE Standard

Certification
China KeLing Purification Technology Company certification
China KeLing Purification Technology Company certification
Customer Reviews
Keling had successfully supplied us following products on 25 Oct.2017 against PO NO.M170807; Their supplied Air Filters have been working satisfactorily since installation.We are satisfied with their products.

—— SIMPOR PHARMA

Since we do coopertae with them, they always offer good quality and keep the delivery on time to us, we do appreicated for their kind support !

—— Nasir

This is to certify that we bought U type air shower tunnel, Air Shower and HEPA filter, Secondary air filter ,perfilter for our project from KeLing Purification Technology Co. Ltd, 3C01 Tian Feng Commerce Square, Mid Building, No. 133, Baiyun AV, Baiyun Disctrict , Guangzhou , GuangDong, China against Contract No: 2014/4119005942 in October 22, 201

—— IATEC,Argentina

Product arrived faster than expected and they sent something special in addition to what I ordered. Nice people and fast service!

—— Mohammed Saad

I'm Online Chat Now

Stainless Steel Pharma Dispensing Booth Laminar Air Flow CE Standard

Stainless Steel Pharma Dispensing Booth Laminar Air Flow CE Standard
Stainless Steel Pharma Dispensing Booth Laminar Air Flow CE Standard Stainless Steel Pharma Dispensing Booth Laminar Air Flow CE Standard

Large Image :  Stainless Steel Pharma Dispensing Booth Laminar Air Flow CE Standard

Product Details:
Place of Origin: CHINA
Brand Name: K-LING
Certification: CE
Model Number: KEL-DB
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Polywood packing
Delivery Time: 7-15 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200 sets per month
Detailed Product Description
Cabinet: Stainless Steel Cabinet Name: Sampling Booth/ Dispensing Booth
Air Flow: Laminar/ Vertical Air Flow Trademark: KEL
Power Source: Electrical Power: 380V/50HZ
High Light:

Pharma Dispensing Booth

,

Laminar Air Flow Dispensing Booth

,

Stainless Steel Dispensing Booth

GMP Clean Room CE Standard Stainless Steel Pharma Dispensing Booth/ Sampling Booth





Parameter



Customer's design is available.



Model
KEL-WB1300
KEL-WB1700
KEL-WB2400
External Dimension (W*D*H)(mm)
1300*1300*2450
1700*1600*2450
2400*1800*2450
Internal Dimension (W*D*H)(mm)
1200*800*2000
1600*1100*2000
2300*1300*2000
Cleanliness
ISO 5(Class 100)
Air Velocity(m/s)
0.45±20%
3-level Filter System
G4-F8-H14
Noise(dB)
≤65
Illumination(Lx)
≥300
Exhaust Air Volume(m3/h)
250
360
900
Supply Air Volume(m3/h)
2500
3600
9000
Max Power Consumption(kw)
≤1.5
≤3
≤3
Control Mode
VFD/PLC(Optional)
Case Material
SUS304
Power Supply
AC380/220V,3 phase,50/60Hz(Optional)







Product introduction


Weighing Booth, Dispensing Booth, Sampling Booth for GMP is a special local purification equipment that is used in the latest version of GMP for the production of sterile preparations. It provides a vertical unidirectional airflow, and some (80%-90%) clean air circulates in the working area. 10%-20% is discharged to the nearby area to create a negative pressure in the work area, prevent cross-contamination to ensure a high cleanliness environment in the work area. It is composed of work area, return air box and fan box cabinet, etc. The control panel is located on the front of work area, which can start the device, adjust air speed and working conditions. It has differential pressure gauges, buzzers and wind speed sensors, which can test the real-time resistance of filters, failure alarm and real-time speed in the work area.







Stainless Steel Pharma Dispensing Booth Laminar Air Flow CE Standard 0

Stainless Steel Pharma Dispensing Booth Laminar Air Flow CE Standard 1











ABOUT US :



GuangZhou HaoAir Purification Technology Co., Ltd is a professional manufacturer in air purification field for many years in China. Our products with good quality, reasonable prices and custom design.

Our main products include the cleanroom air shower , cargo air shower , static pass box , dynamic pass box , dispensing booth , vertical / horizontal laminar air flow clean cabinet , air filter,etc. AII of products can be customized.

Our customers come from Pakistan , Chile , India , Algeria , Nigeria, Italy , Czech Republic , ect.
