Product Details:
|
Door: | PVC Rolling Door | Speed: | 25-27m/s |
---|---|---|---|
Name: | Cargo Air Shower | Other Name: | Air Shower Tunnel |
Original: | China | Warranty: | 1 Year |
Highlight: | Infrared Induction Cargo Air Shower Room,Rolling Shutter Door Air Shower Room,780W Air Shower Room |
Warehouse Rolling Shutter Door Infrared Induction Air Shower Customized Size
Introduction
Compared with traditional cargo shower, the fast rolling curtain door cargo shower is equipped with infrared induction door closing and shutting system, the door closing switch is canceled and reach full automation function. When the showering process for person or cargo is finished, the curtain door will open and and shut after the cargo and person moving out tunnel. The two curtain door is equipped with two separate electronic interlock, played "gas chamber”,when one side door is open, the other side door will shut and locked at the same time. It will effectively prevent the polluted air to enter purified area. The hair,dust, bacteria can be blocked outside clean workshop so the purified level in working area can be ensured.
Air Shower Tunnel Parameter
Model | KEL-AS1290/1 | KEL-AS1290/2 | KEL-AS1290/3 | Air Shower Tunnel | |
External Dimension | 1290×1000×2050 | 1290×1000×2050 | 1290×2000×2050 | 1950×5000×2050 | |
Internal Work Zone | 790×860×1910 | 790×860×1910 | 790×1860×1910 | 790×4860×1910 | |
Suitable Number | 1-2 person | 1-2 person | 2-4 person | Tunnel type | |
Noise Level(dB) | <62 | <62 | <62 | <62 | |
Stainless Steel Nozzle | 6PCS | 12PCS | 24PCS | 72PCS | |
Wind Speed | ≥25m/s | ≥25m/s | ≥25m/s | ≥25m/s | |
Prefilter | Size | 775×380×17×1pc | 775×380×17×2pc | 775×380×17×4pc | 775×380×17×6pc |
Efficiency | G4 | G4 | G4 | G4 | |
HEPA Filter |
Size | 610×610×120×1pc | 610×610×120×2pc | 610×610×120×4pc | 610×610×120×8pc |
Efficiency | 99.99%@0.3µm | 99.99%@0.3µm | 99.99%@0.3µm | 99.99%@0.3µm | |
Fluorescent Lamp |
20W×1 | 20W×1 | 20W×2 | 40W×4 | |
Power Supply | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz | |
Total Power | 780W | 780W | 780W | 780W | |
Display
