Product Details:
|
| Efficiency: | H13 / H14 | Frame: | Aluminum Frame |
|---|---|---|---|
| Filter Media: | Glassfiber Paper | Sealant: | Polyurethane |
| Size: | Customized | Max. Temperature: | 80°C |
| Highlight: | Rigid Hepa Carbon Air Filter System,Rated Industrial Activated Carbon Pre Filter,99.99% Efficiency Carbon Air Filter System |
||
Advantage:
Individually tested HEPA/ULPA filter in an enclosure assembled without penetrating fasteners
Unique seamless poured-in-place gasket ensures leak free performance when installed into housings or built-up filter banks
Construction:
Industiral Air Filter uses an adhensive seal around the perimeter of the media pack to create a positive seal, between the media pack and the frame, that eliminates the bypass of dirty air. Some competitive filters use a piece of fiberglass as the sealing mechanism. This fiberglass media can shed filter fibers and does not assure a positive seal.
| Model |
Dimensions (mm) W×H×D |
Rated air flow m3/h |
Initial resistance pa |
Efficiency % |
Material | |||
| Media | Separator | Sealant | Frame | |||||
| HEK-HF |
305*305*150 305*610*150 610*610*150 762*610*150 915*610*150 305*305*292 305*610*292 610*610*292 |
300 500 1000 1200 1500 600 1000 2000 |
<220
|
>99.99 Sodium flame |
Fiberglass paper |
Aluminum foil; sized paper |
Polyurethane Rubber PU |
Galvanized steel Frame |
