Class1000 Modular Hardwall Clean Room With High Efficiency Air Filter
Quickly detail
Extenral size :6000x3000x2596mm
Internal Size: 5900x2900x2205mm
Purification rank: Class10000
HEPA filter efficiency: 99.999%@0.3um
Laminar flow: vertical
Air speed :0.3-0.6m/s
Power: 220V/50HZ
Introduction:
hardwall Cleanroom (Simplified Clean Room) is a local air purification equipment to provide high- clean environment, is a clean room which the most quickly and easily create. Clean shed main consist of cabinet, fan, prefilter and HEPA filter, damping layer, lamps and other components. It can be suspended, but also can be ground support, compact structure, easy to use. Can use single or multiple connections to compose of banded clean area.
Clean shed interior cleanliness can be reached100-100000class level, in order to reduce structural costs of clean shed, haoairtech changed the traditional concept of clean shed design, take a modular integrated design concept , this structure has a variety of separate clean area, for some areas of general clean class level clean room that required high clean class level do local creation to reduce costs, thus making the workers and equipment, products effectively isolated, can minimize the pollution, thereby increasing the rate of qualified products.
Applications:
Food industry, aerospace, life sciences, biotechnology, medical devices, plastic injection module, electronics assembly or hospital pharmacy
Illustration:
1: The frame is steel cube with milk powder coated.
2: M support leg
3: The wall made from clarity synthetic glass.
4: FFU control box.
5: FFU with HEPA filter and pre-filter
6: Purification lamp
7: PVC strip curtain
8: Purification rank class10000 (FS209E Stander)
Technical Parameter:
|
MODEL
|
KEL-LFB6000
|
|
Ex size (mm)
(W*D*H)
|
6000X3000X2596mm
|
|
In size (mm)
|
5900x2900x2205mm
|
|
Purification rank
|
Class10000(FS209E USA)
|
|
HEPA filter
|
Efficiency : 99.99% @ 0.3um - 99.999% @ 0.12um (MPPS)
|
|
Pre-filter
|
Efficiency : 85% @ 5um
|
|
Control system
|
PC control system / promised speed by control box
|
|
Pressure Gauge
|
American Dywer pressure
|
|
Noise
|
<50-55 dB (test point distance is 1m)
|
|
Air velocity
(m3/h)
|
0.2-0.5m/s Adjustable (test point distance is 30cm)
|
|
Frame material
|
stainless steel/steel with power coated/Cast aluminum profile
|
|
Wall frame
|
Tempered glass / PVC anti-static curtain (option)
|
|
Fan
|
EBM Fan /Taiwan fan/ Domestic fan (option)
|
|
Power suppler
|
AC110/220v 50HZ/60HZ
|
Customer’s design is available.
Applications:
Food industry, aerospace, life sciences, biotechnology, medical devices, plastic injection module, electronics assembly or hospital pharmacy
Why you choose K-LING Company ?
1. Superior Quality
Quality is our biggest concern. We are always striving for quality improvement from the first beginning.
2. Competitive Price
Competitive price is one of our advantages compared to
others. We are always working hard to lower down the cost
while still improve or keep the quality.
3. Customer first service
Focus on customization, we provide the free design by our designers. Reply with 24 hours if any questions and pack in time for delivery.
4. All-in-one convenience
We are dedicated to give you all-in-one service. You just tell us your demand, then we will take care of your demand, design drawings, build the clean room and provide you best after sale.
5. Product diversification
We are not only undertake clean room construction, clean booth construction, etc., but also an agent to export accessories from other factory. You could always choice the suitable products in our company.
