Product Details:
|
| Material: | Stainless Steel 304 | Door: | Automatic Sliding Door |
|---|---|---|---|
| Certification: | CE | Applicable Object: | People Shower |
| Trademark: | KEL | Origin: | GuangZhou China |
| Highlight: | air shower system,electronics clean room |
||
Automatic Sliding Door Air Shower Tunnel With LCD Display CE Certification
Introduction
Air shower is a strong purification equipment, installed between the clean room and non-clean room. The dust carry on the woker will be remove by blowing leaching before the worker into the clean room.It can effectively block or reduce the source of dust into the clean area. Airshower around two doors for electronic interlocking, but also play the role of an airlock, preventing unpurified air into the clean area.
Advantages
Our automatic door air shower's advantages and functions are as follows:
1) Door open method: automatic sliding door by photoelectric sensor. When personnel enter air shower, the door will open automatically. When personnel go out of it, the door will be closed automatically. The control system run automatically, the two doors electronically interlocked, with photoelectric sensor (one door in open state, the other door must be in closed state. When personnel enter it, the system will shower automatically by photoelectric sensor);
2) Material: Stainless Steel SUS304 ;
3) LCD Display, touch-point switch to control blowing time and lamp time;
4) Infrared sensor automatic blowing, automatic stop;
5) Three-side blowing, left, right, and top, stainless steel nozzles;
6) 360-degree rotatable nozzles are installed according to customers' needs to keep high efficiency for blowing off particles from personnel;
7) Have electronic interlock air shower patent.
Technical Parameters
| Model | KEL-AS1 | KEL-AS2 | KEL-AS3 | KEL-AS4 |
| Applicable Number of People | 1 | 3-4 | 4-5 | 5-6 |
| Air Shower Time | 0- 99s (Adjustable) | |||
| Number of Nozzle | 12 (two Sides) | 24 ( two Sides ) | 36 ( two Sides ) | 48( two Sides ) |
| Mouth Diameter of Nozzle | Φ 30 mm | Φ 30 mm | Φ30 mm | Φ30 mm |
| Air Velocity at the Nozzle | >25m/s | >25m/s | >25m/s | >25m/s |
| Dimension of High Efficiency Air Filter (mm) | 600×600×120 | 600 ×600×120 | 600×600×120 | 600×600×120 |
| Dimension of Air Shower Area (mm) | 800×1000×1960 | 800×2000×1960 | 800×3000×1960 | 800×4000×1960 |
| Outside Dimension (mm) | 1700×1240×2200 | 1700×2240×2200 | 1700×3240×2200 | 1700×4240×2200 |
| Power Supply:380V,50HZ, we can made nonstandard voltage for different country. | ||||
| Maximum Power Consumption | 1.5KW | 3KW | 4.5KW | 6KW |
Other type air shower
