Class 100 High Efficiency Softwall Clean Room for Semiconductor Industry
Quickly detail
Extenral size :5000x5000x2596mm
Internal Size: 4900x4900x2205mm
Purification rank: Class100-10000
HEPA filter efficiency: 99.999%@0.3um
Laminar flow: vertical
Air speed :0.3-0.6m/s
Power: 220V/50HZ
Introduction:
Softwall clean room booth is a Simplified Clean Room that is a local air purification equipment to provide high- clean environment., is a clean room which the most quickly and easily create. laminar flow booth main consist of cabinet, fan, prefilter and HEPA filter, damping layer, lamps and other components. It can be suspended, but also can be ground support, compact structure,easy to use. Can use single or multiple connections to compose of banded clean area.
Applications:
Food industry, aerospace, life sciences, biotechnology, medical devices, plastic injection module, electronics assembly or hospital pharmacy
Operating features
1: The ceiling enables flexible placement of fan filter unit, the empty bays cover by powder coated steel panels.
2: the construction utilizing full welded, reinforced, steel tubular sections. The frame is finished with an abrasion-resistance oven-baked powder coat, it is free-standing not require any suspending ceiling supports
3: the PVC anti-static curtain door allowing for easy passage of material and personnel in and out of the clean area. The curtain terminated at a specific distance above the floor to allow for exhaust of clean air out of the clean room.
4: Control box can rapid start up the fan filter unit and lighting.
5: Fan filter unit is the energy efficient external rotor motor design reduces operating costs and has extremely low noise and vibration levels, improving the working conditions in the clean room.
6: the high quality mini-pleats HEPA filter utilizing an improved mini-pleated separation technique to maximize surface area improves efficiency and extends the filter life.
Illustration:
1: The frame is steel cube with milk powder coated.
2: M support leg
3: The wall made from clarity synthetic glass.
4: FFU control box.
5: FFU with HEPA filter and pre-filter
6: Purification lamp
7: PVC strip curtain
8: Purification rank class100-1000 (FS209E Stander)
Configuration:
| Parameter | Softwall Clean Booth | Hardwall Clean Booth |
| Cleanliness | From Class 100 to Class 1000,000 |
| External Dimension | As per requirement |
| FFU | Dimension | 2'X4' |
| Cabinet Material | Stainless Steel |
| Power source | 110V/60hz/av/dc, 220V/60HZ/AV/DC |
| HEPA Filter | H14 Hepa filter |
| Frame Material | Stainless Steel |
| Wall Material | Anti-static soft PVC wall 106~109Ω | Anti-static acrylic 106~109Ω |
| Lighting | Lamps | Available in LED and T5 |
| Air condition | As per requirement | Available in constant temperature air conditioner/constant temperature and humidity conditioner |
Besides above configuration, we can customized as required.
Applications:
Food industry, aerospace, life sciences, biotechnology, medical devices, plastic injection module, electronics assembly or hospital pharmacy
Why you choose K-LING Company ?
1. Superior Quality
Quality is our biggest concern. We are always striving for quality improvement from the first beginning.
2. Competitive Price
Competitive price is one of our advantages compared to
others. We are always working hard to lower down the cost
while still improve or keep the quality.
3. Customer first service
Focus on customization, we provide the free design by our designers. Reply with 24 hours if any questions and pack in time for delivery.
4. All-in-one convenience
We are dedicated to give you all-in-one service. You just tell us your demand, then we will take care of your demand, design drawings, build the clean room and provide you best after sale.
5. Product diversification
We are not only undertake clean room construction, clean booth construction, etc., but also an agent to export accessories from other factory. You could always choice the suitable products in our company.
Semiconductor Industry softwall cleanroom :
Semiconductor Industry softwall cleanroom 2:
Fan filter unit for the softwall cleanroom :
