Product Details:
Payment & Shipping Terms:
|
| Place Of Origin: | GuangZhou China | Name:: | Cargo Air Shwoer / Cargo Air Shwoer Tunnel |
|---|---|---|---|
| Color: | Silver Gray | Size: | Customizable |
| Wind Velocity: | 25-30 M/s | Blowing Direction: | 3 Side |
| High Light: | air shower system,electronics clean room |
||
Customizable Automatic Induction Door Goods Air Shower Tunnel Three-sided Shower
Introduction
The Airshower Tunnel is an essential equipment used in semiconductor, electronics, and other industries. The equipment is designed to provide a high-speed, uniform airflow that eliminates any particle that may have adhered to the personnel or material before entering the cleanroom. The article discusses the technical specifications of the airshower tunnel to provide insights into which configuration would be suitable for specific environments.
Technical Specifications
The Airshower Tunnel is equipped with high-efficiency particulate air filters (HEPA), which can capture particles greater than and smaller than 0.3 microns. The tunnel comes in various configurations, depending on several various factors, including the number of personnel, materials, or equipment entering the cleanroom. The following are some of the technical specifications of the Airshower Tunnel:
Dimensions
The equipment dimensions vary depending on the configuration. The dimensions of the standard equipment are approximately 1400mmx1710mmx 2300mm.
Air Volume Capacity
The air volume capacity also varies depending on the configuration. The range varies between 800m3/h to 2400m3/h.
Airflow Velocity
The airflow velocity provided by the Airshower Tunnel ranges between 20m/s to 25m/s. The velocity is designed to provide a laminar, high-speed airflow that can effectively remove any loose contamination present on the surface of the personnel or material.
Material Composition
The Airshower Tunnel is made of high-quality materials that are durable and resistant to corrosion. The equipment is primarily composed of high-grade stainless steel, while the panels are made of high-quality cold-rolled steel sheets. The floors are coated with anti-static flooring, while the ceilings are integrated with LED lights for optimal lighting conditions.
Working Principle
The air shower principle of the equipment is based on high-speed, turbulent airflows generated by nozzles located at specific positions, ensuring the desired level of flow and turbulence is achieved. The velocity of the airflow ensures that loose contaminants on the personnel or material are exposed to strong air streams that can blow them off.
Applicable Areas
The Airshower Tunnel is used in various cleanroom environments in semiconductor, electronics, and other industries. The equipment is crucial in maintaining a clean environment that ensures high-quality outcomes.
Product parameters
| Goods Air Shower Tunnel | |||
| MODEL | KEL-AS1400T-4 | ||
|
External size (mm) (WXDXH) |
1400x4000x2180mm | ||
|
Work zone (mm) (WXDXH) |
1000x3860x1910mm | ||
| Persons per cycle | 10-50 person | ||
| Air shower Duration | Factory set at 12 second (adjustable) | ||
| Air shower direction | Three side with blowing | ||
|
Material (Option) |
1: Entirety Sus304. 2: Entirety sus201. 3: External is steel with power coated, Internal is SUS304. 4: External is steel with power coated. Internal is SUS201. |
||
| Control system |
1: PCL control system with LED display for the shower time. 2: The shower time from 0-99second. (Adjustable). 3: Infrared ray inductor for inside personal shower automatic. 4: Human voice prompt system. 5: with CE remark. |
||
| The power of Fan | 380V/50HZ/750W (2 set) | ||
| Air flow of fan(m3/h) | 1300m3/h | ||
| Fan run (r/min) | 2800r/min | ||
| Nozzle in stain less steel | 88 pcs | ||
| Wind speed(m/s) | 25-29m/s | ||
| Noise level(dB) | <62dB | ||
| LED Fluorescent Lamp | 20wx4 | ||
|
HEPA Filter |
Size(mm) | 630X630X69mm | |
| Efficiency | 99.99%@0.3um | ||
| Air velocity | 1000(m3/h) | ||
| Initial resistance(pa) | <220pa | ||
|
Pre-filter |
Size(mm) | 775x380x17 | |
| Efficiency | 75% @ 0.5um | ||
| Resistance(pa) | <30 Pa | ||
| Electrical | Power supply | 380v/50Hz | |
| Net power(kw) | 0.75X4 kw | ||
Customer’s design is available.
Case presentation
