| Material: | Powder Coated Steel | Noise: | <62 DB(Test Point Distance Is 1 M) |
|---|---|---|---|
| Size: | Customizable | Air Velocity: | 25-30 M/s |
| Power: | 380V/50HZ | Warranty: | 1 Year |
| High Light: | air shower system,electronics clean room |
||
Powder Coated Steel Automatic Sliding Door Air Shower Tunnel For Electronic factory
Introduction
Airshower tunnel is an air shower equipment designed to provide clean air streams to personnel, materials and equipment that require access to a cleanroom environment. The article discusses the principles by which the Airshower Tunnel functions to emphasize its crucial role in the clean environment.
Working Principle
The airshower tunnel operates based on the principle of high-speed, turbulent airflows through which particles are removed from the surface of the personnel or material. The airflow is provided through nozzles that are located at specific positions, ensuring that the desired level of flow and turbulence is achieved. The velocity of the airflow exposes any loose contaminants on the personnel or material to strong air streams that blow them off.
Technical Specifications
The equipment consists of a blower, an air filter, nozzles, and a metal enclosure. The incoming air passes through high-efficiency particulate air filters (HEPA) that removes particles larger and smaller than 0.3 microns. The filtered air is then forced out of the nozzles, providing a laminar, high-speed airflow in the range of 20-25m/s.
Structure and Composition
The shower room itself is constructed from high-grade stainless steel, which is resistant to rust and corrosion. The interior is equipped with nozzles or a group of nozzles that spray air particles to form a strong wind shower. The floors and ceilings are coated with anti-static floors, whereas the doors are designed to avoid any direct contact. The unit is equipped with LED lights to ensure maximum lighting conditions.
Parameter
| KEL-AS1300T-7T Air Shower Tunnel | ||
| MODEL | KEL-AS1300T-7T | |
|
External size (mm) (WXDXH) |
1200x7500x2180 | |
|
Work zone (mm) (WXDXH) |
800x7360x1910 | |
| Persons per cycle | 10-50 person | |
| Air shower Duration | Factory set at 12 second (adjustable) | |
| Air shower direction | Three side with blowing | |
|
Material (Option) |
1: Entirety Sus304. 2: Entirety sus201. 3: External is steel with power coated, Internal is SUS304. 4: External is steel with power coated. Internal is SUS201. |
|
| Control system |
1: PCL control system with LED display for the shower time. 2: The shower time from 0-99second. (Adjustable). 3: Infrared ray inductor for inside personal shower automatic. 4: Human voice prompt system. 5: with CE remark |
|
| The power of Fan |
380V/50HZ/750W (6 sets) |
|
| Air flow of fan(m3/h) | 1300m3/h | |
| Fan run (r/min) | 2800r/min | |
| Nozzle in stain less steel | 100 pcs | |
| Wind speed(m/s) | 23-29m/s | |
| Noise level(dB) | <62dB | |
| LED Fluorescent Lamp | 20wx6 | |
|
HEPA Filter |
Size(mm) | 630X630X69mm |
| Efficiency | 99.99%@0.3um | |
| Air velocity | 1000(m3/h) | |
| Initial resistance(pa) | <220pa | |
|
Pre-filter |
Size(mm) | 775x380x17 |
| Efficiency | 75% @ 0.5um | |
| Resistance(pa) | <30 Pa | |
| Electrical | Power supply | 380v/50Hz or 380v |
| Net power(kw) | 0.75X6 kw | |
Customer’s design is available.
Air shower tunnel structure diagram
This is a three-side blow, 36 nozzle air shower tunnel installation drawing
Installation method: the box and the top plate, the box and the door are locked with connecting screws
Air shower tunnel detail
