Name: | Power Coated Steel Cleanroom Air Shower | External Size(W*D*H): | 1200X1000X2180mm |
---|---|---|---|
Internal Size(W*D*H): | 800X930X1910mm | Persons Per Cycle: | 1-2persons |
SUS Nozzle: | 12pcs | Air Flow: | 1300 M3/h |
Highlight: | semiconductor clean room,lab clean room |
Automatic Power Coated Steel Cleanroom Air Shower With PLC Control System
Introduction :
Power coated steel cleanroom air shower is the necessary passage for people to enter the clean room , which can reduce the pollution problems caused by people entering and leaving the clean room . The air shower series is a versatile partial purification device installed between the clean room and the non-clean room . When people and goods enter the clean area , they need to be blown through the air shower . The clean air from stainless steel nozzles blown out can remove the dust carried by people and can effectively block or reduce the dust source from entering the clean area . The front and rear doors of the power coated steel air shower are electronically interlocked and can also act as air locks to prevent unpurified air from entering the clean area .
Features :
1. Completely self - contained , pre - wired , fully equipped air shower system helps solve the purification problem .
2. Solid - state microprocessor panel provides programmable control of access control operations .
3. Electronic interlocking doors of the power coated steel air shower can efficiencially minimize pollution .
4. The power coated steel cleanroom air shower has an emergency button , and the electronic interlock door is automatically released when the power fails or the emergency stop button is pressed .
5. Energy - saving LED lighting installed on the ceiling .
6. Provide white powder coating or stainless steel to meet various clean room requirements .
7. Multiple sizes and door configurations , such as Single - door , including horizontal sliding door and 90 swing door , Double - door , horizontal sliding door and 90 swing door , vertical roll - up door .
Photographs :
Parameters :
Power Coated Steel Cleanroom Air Shower | |||||
Model | KEL – AS1200/P1 | KEL – AS1200/P2 | KEL – AS1200/P3 | ||
External Size (W*D*H)mm |
1200X1000X2180 | 1200X2000X2180 | 1200X3000X2180 | ||
Internal Size (W*D*H)mm |
800X930X1910 | 800X1930X1910 | 800X2930X1910 | ||
Persons per cycle | 1-2persons | 2-4persons | 3-6persons | ||
Air Flow(m3/h) | 1300 | ||||
Fan Rate(r/min) | 2800 | ||||
SUS Nozzle | 12pcs | 24pcs | 36pcs | ||
Wind Speed(m/s) | ≧20-25 | ||||
Noise Level | <62dB | ||||
Hepa Filter | Size | 610X610X100mm | |||
Efficiency | 99.99% @0.3um | ||||
Resistance | <220pa | ||||
Pre-filter | Size | 750X350X21 | |||
Efficiency | 75% @5um | ||||
Resistance | <30pa | ||||
Electrical | Power | 380V/50HZ |
About Us :
GuangZhou HaoAir Purification Technology Co., Ltd is a professional manufacturer in air purification field for many years in China. Our products with good quality, reasonable prices and custom design.
Our main products include the cleanroom air shower , cargo air shower , static pass box , dynamic pass box , dispensing booth , vertical / horizontal laminar air flow clean cabinet , air filter,etc. AII of products can be customized.
Our customers come from Pakistan , Chile , India , Algeria , Nigeria, Italy , Czech Republic , ect.
