Product Details:
|
| Name: | Cargo Air Shower | Material: | SS304,Coldrolled Steel With Bake Painting |
|---|---|---|---|
| Blowing Way: | 3 Sides | SUS Nozzle: | 36pcs |
| Air Speed: | >25m/s | Application: | Electronics / Microelectronics / Precision Electronics / Biomaterials / Healthcare / Food Processing / ITO Mode / LCD And Optoelectronics Industry/ PCB / SMT Manufacturing / Aerospace / Automotive / Dust-free Coating Industry And Other Industries. |
| Highlight: | semiconductor clean room,lab clean room |
||
Customized Cargo Air Shower With Fast Rolling Door For Industries
Automatic induction door cargo shower working principle:
Automatic induction door cargo shower is on the basis of traditional goods shower room, with the advanced infrared sensor automatic door machine system, automatic induction door cargo shower compared with traditional goods shower room is cancelled, door closers, thereby making goods shower room is truly realized the full automation .
Goods in automatic induction door cargo shower drench when blowing through the infrared induction automatic induction, automatic door goods shower room to open the door and close, after the goods of dust removal, the automatic door goods shower room will automatically open and close again go out, the whole process of automatic door goods shower room dust are all automatically move the door.
Automatic door of shower room for automatic parallel moving around, it can reduce the pollution of the problems of goods in and out of the clean room.
| MODEL | KEL-AS2300P2 | KEL-AS2300P3 | |||
|
External size (mm) (W*D*H) |
2300x2000x2280mm | 2300x3000x2280mm | |||
|
Work zone (mm) (W*D*H) |
1500x2000x1980mm | 1500x3000x1980mm | |||
| Persons per cycle | One Small Cargo forklift. | One big Cargo forklift. | |||
|
Material (Option) |
1:External is steel with power coated, Internal is SUS304(T=1.0/1.2/1.5mm) 2:External is steel with power coated. Internal is SUS201(T=1.0/1.2/1.5mm) |
||||
| Control system |
1: Control system with LED display for the shower time. 2: The shower time from 0-99second. (Adjustable) 3: Infrared ray inductor for inside personal shower automatic. 4: Three side blowing with Human voice prompt system. 5: with CE remark. |
||||
| Door | Automatic High Speed Rolling Door | ||||
| The power of fan |
380V/50HZ/0.75KW (4 set) |
380V/50HZ/0.75KW (6sets) |
|||
| Air flow of fan(m3/h) | 1500 | 1500 | |||
| Fan run (r/min) | 2800 | 2800 | |||
| Nozzle in stain less steel | 36 pcs | 54 pcs | |||
| Wind speed(m/s) | >25m/s | ||||
| Noise level(dB) | <75dB | ||||
| HEPA FILTER | Size(mm) | 630X630X80mm(4 sets) | 630X630X80mm(6 sets) | ||
| Efficiency (%) | 99.995% @ 0.3um mini-pleats HEPA Air Filter | ||||
| Air velocity | 1000(m3/h) | ||||
| Initial resistance(pa) | <180pa | ||||
| Pre-filter | Size(mm) | 775x380x17 | 775x380x17 | 775x380x17 | |
| Efficiency (%) | 75% @ 0.5um | 75% @ 0.5um | 75% @ 0.5um | ||
| G3 | G3 | G3 | |||
| resistance(pa) | <30 Pa | <30Pa | <30 Pa | ||
| parameter | Power supply | 380v/50HZ 3P | 380v/50HZ 3P | 380v/50HZ 3P | |
| Net power(kw) | 1.5 kw | 3kw | 4.5 kw | ||
