Class 100 Cleanroom Air Shower with PLC Control and Stainless Steel SUS304 Construction for Merchandise

Large Image : Class 100 Cleanroom Air Shower with PLC Control and Stainless Steel SUS304 Construction for Merchandise

Product Details:

Place of Origin:	China
Brand Name:	KELING
Certification:	CE
Model Number:	KEL-AS1300P3

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	Polywood Packing
Delivery Time:	8-15 working days
Payment Terms:	L/C,Western Union,T/T,MoneyGram
Supply Ability:	30 sets per month

Contact Now

Class 100 Cleanroom Air Shower with PLC Control and Stainless Steel SUS304 Construction for Merchandise

Description

Material:

Stainless Steel

Highlight:

semiconductor clean room

lab clean room

Two Side Blow Class 100 SUS304 Cleanroom Air Shower for Merchandise

Product Overview

Two Side Blow Class100 SUS304 Air Shower Room With PLC Control System for Merchandise

Custom Air Shower Configurations

We build custom cleanroom entry systems to match nearly any specification. With numerous customizable options, the possibilities are virtually endless. The examples below represent just a sample of our custom clean room air shower capabilities.

Standard-Profile 90° Air Showers: Feature multiple 90° entry/exit options designed for quick, effective particle removal. Available with one, two, or three right- or left-hand oriented doors.
Standard-Profile 90° ADA Compliant Air Showers: Built slightly larger than standard models to accommodate wheelchair access with automatic doors and other unique features.
Low-Profile Straight-Through Air Showers: Measure just 95" in height with blower assembly, HEPA filter, and electrical components mounted on the side rather than on top.
Low-Profile Tunnel Air Showers: Available in 2-unit, 3-unit, 4-unit, and 5-unit configurations for low ceiling heights (102" minimum). Extended length allows for additional air nozzles.
Low-Profile Straight-Through ADA-Compliant Air Showers: Designed with wider entry/exit points and lower ceiling height (95") for wheelchair accessibility in tight spaces.
Low-Profile 90° ADA-Compliant Air Showers: Feature 90° turns with larger doors and shorter overall height (95") for wheelchair access in space-constrained applications.
Parts-Cleaning Straight-Thru Air Showers: Specially designed to decontaminate carts, conveyors, pallets, and other part delivery systems.

Product Specifications

MODEL	KEL-AS1950P2	KEL-AS1950P3
External size (mm) (WDH)	1950x2000x2180mm	1950x3000x2180mm
Work zone (mm) (WDH)	1450x1930x1910mm	1450x2930x1910mm
Capacity Per cycle	One Small Cargo forklift	One big Cargo forklift
Material (Option)	1: External is steel with powder coated, Internal is SUS304 (T=1.0/1.2/1.5mm) 2: External is steel with powder coated, Internal is SUS201 (T=1.0/1.2/1.5mm) 3: External and internal is steel with powder coated (T=1.0/1.2/1.5mm)
Control system	1: Control system with LED display for shower time 2: Shower time from 0-99 seconds (Adjustable) 3: Infrared ray inductor for inside personal shower automatic 4: Three side blowing with Human voice prompt system 5: With CE remark
The power of fan	380V/50HZ/0.75KW (4 sets)	380V/50HZ/0.75KW (6 sets)
Air flow of fan(m³/h)	1500	1500
Fan run (r/min)	2800	2800
Nozzle in stainless steel	36 pcs	54 pcs
Wind speed(m/s)	>25m/s
Noise level(dB)	<75dB
HEPA FILTER	Size(mm): 630X630X80mm (4 sets) Efficiency (%): 99.995% @ 0.3um mini-pleats HEPA Air Filter Air velocity: 1000(m³/h) Initial resistance(pa): <180pa	Size(mm): 630X630X80mm (6 sets) Efficiency (%): 99.995% @ 0.3um mini-pleats HEPA Air Filter Air velocity: 1000(m³/h) Initial resistance(pa): <180pa
Pre-filter	Size(mm): 775x380x17 Efficiency (%): 75% @ 0.5um G3 Resistance(pa): <30 Pa	Size(mm): 775x380x17 Efficiency (%): 75% @ 0.5um G3 Resistance(pa): <30 Pa
Parameter	Power supply: 380v/50HZ 3P Net power(kw): 3 kw	Power supply: 380v/50HZ 3P Net power(kw): 4.5 kw
Packing size (mm)	2050x2100x2250mm	2050x3200x2250mm
Packing material	Standard Export Poly wood Packing (Fumigant free material)
Weight	650kgs	960kgs
