Purification Air Shower Cleanroom For GMP Workshop With 3 Directional Blowing
CUSTOMIZED DESIGN IS AVAILABLE
General Trade Information:
Brand: KELING
Model number: KEL-AS1400V Series
Material: inside and outside is stainless steel304 (t=1.0mm)
OEM /ODM: Yes
Certificated: CE and Rosh
Start port: Guangzhou,Shenzhen
Delivery time: 8 working days after we get the deposit.
MOQ: 1sets
Country of Original: China
Supply ability: 30 set/one month
Payment term: T/T , L/C , Western union ,
Application: Worker in Clean room
Alternative configuration:
a. Stainless steel construction
b. Intercom
c. Ultraviolet sterilizing lamp/yellow light
d. Buzzer
e. Non-flooring-plate design (easy for light- weight vehicle in and out)
f. Automatic door
g. Non-standard air shower cleanroom is available
Products Sheet:
| MODEL | HA-AS1400V1 | HA-AS1400V2 | HA-AS1400V3 | |
|
External size (mm) (WXDXH) |
1400x1000x2180 | 1400x2000x2180 | 1400x3000x2180 | |
|
Work zone (mm) (WXDXH) |
790x930x1910 | 790x1930x1910 | 790x2930x1910 | |
| Persons per cycle | 1-2 person | 2-4 person | 3-6 person | |
|
Material (Option) |
1:Entirety Sus304.(T=1.0/1.2/1.5mm) 2:Entirety sus201. (T=1.0/1.2/1.5mm) 3: External is steel with power coated, Internal is SUS304 4: External is steel with power coated. Internal is SUS201 |
|||
| Control system |
1: Control system with LED display for the shower time. 2: The shower time from 0-99second. (Adjustable) 3: Infrared ray inductor for inside personal shower automatic. 4: Vertical top side blowing with Human voice prompt system. 5: with CE remark. |
|||
| The power of fan |
380V/50HZ/1.1KW (1 set) |
380V/50HZ/1.1KW (2 sets) |
380V/50HZ/1.1KW (1sets) |
|
| Air flow of fan(m3/h) | 1500 | 1500 | 1500 | |
| Fan run (r/min) | 2800 | 2800 | 2800 | |
| Nozzle in stain less steel | 16 pcs | 32 pcs | 48pcs | |
| Wind speed(m/s) | >25m/s | |||
| Noise level(dB) | <75dB | |||
| HEPA FILTER | Size(mm) | 630X630X80mm | 630X630X80mm | 630X630X80mm |
| Efficiency (%) | 99.995% @ 0.3um Mini-pleats HEPA air filter | |||
| Air velocity | 1000m3/h | |||
| Initial resistance(pa) | <220pa | |||
| Pre-filter | Size(mm) | 775x380x17 | 775x380x17 | 775x380x17 |
| Efficiency(%) | 75% @ 0.5um | 75% @ 0.5um | 75% @ 0.5um | |
| G3 | G3 | G3 | ||
| resistance(pa) | <30 Pa | <30Pa | <30 Pa | |
| parameter | Power supply | 380v/50Hz | 380v/50Hz | 380v/50Hz |
| Net power(kw) | 1.5 kw | 3kw | 4.5 kw | |
| packing size (mm) | 1500x1200x2250 | 1500x2200x2250 | 1500x3200x2250 | |
| Packing material | Standard Export Poly wood Packing(Fumigant free material) | |||
| Weigh | 320kgs | 650kgs | 960kgs | |
Draw:
Illustrate:
1: Control board 2: Infrared Indicator 3: Per-filter
4: Power Indicator 5: Emergency switch 6: Working light
7: HEPA air filter (H13 99.995%@0.3um) 8: Door 9: Fan
10: Door Closer 11: Nozzle 12: Purification light
Company Information
Our factory with competitive price
Automatic production line.
Nearly 20 years experience in cleanroom industry.
We are an expert in providing customized solutions.
Timely delivery with perfect quality.
Fortune 500 companies’ choice.
Have passed ISO9001.2008 certification.
Our Service:
1: Document
A: Document for custom clear: 1 sets
B: Assemble draw: 1 pcs
C: Circuit diagram draw: 1 pcs
D: Test report : 1sets
E: Additional IQ/OQ/PQ document is available upon request.
2: Air Shower Spare Part so that you can replacement in future by yourself:
A: HEPA air filter +Pre-filter (as your request)
Note: HEPA air filter should be replacement in half and one year. Pre-filter
should be replacement in each 6 months, but it can refresh no more than 3 times
B: Sensor (As your request)
C: Control board (as your request)
3: The air shower guarantee time is 2 years excluding consumable parts and
Accessories .
