Product Details:
Payment & Shipping Terms:
|
Efficiency: | H13 / H14 | Frame: | SUS 304 Frame |
---|---|---|---|
Filter Media: | Glassfiber Paper | Separator: | Yes |
Size: | Customized | Max. Temperature: | 80°C |
High Light: | Deep Pleated H13 Filter,Low Pressure Drop H13 Filter,SUS 304 Frame H13 Filter |
Product Details
Good quality and high performance super fine glass fiber, over-length glass fiber, pp fiber filter paper and so on are used as filter medium and aluminum foil or two-sided offset paper is used as spacer. Many kinds of efficiencies, from medium efficiency (M6~F9),Sub-high efficiency(H10~H12)to high efficiency(H13~H14),are provided to customers for choice. Wide size are available.
Features
1. Ultra-fine glass fiber as filter media.
2. Separator design, high efficiency, low pressure drop,
high dust loading capacity.
3. Applicable to VAV system.
4. Efficiency: 65%(M6),85%(F7),
90%(F8),95%(F9)(EN779)
99.95%@MPPS(H13) (EN1822)
99.995%@MPPS(H14) (EN1822)
Parameter
Model |
Width (mm) |
Height (mm) |
depth (mm) |
Nominal air flow and resistance (m3/h&pa) |
Efficiency Sodium flame method (%) |
Dust collection (g) |
KEL1260-630-220 |
1260 |
630 |
220 |
3000/220 |
99.99 |
1800 |
KEL648-630-220 |
948 |
630 |
220 |
2200/220 |
99.99 |
1400 |
KEL1220-610-150 |
1220 |
610 |
150 |
2000/220 |
99.99 |
1200 |
KEL968-484-220 |
968 |
484 |
220 |
2000/220 |
99.99 |
1200 |
KEL915-610-150 |
915 |
610 |
150 |
1500/220 |
99.99 |
800 |
KEL726-484-220 |
726 |
484 |
220 |
1500/220 |
99.99 |
750 |
KEL630-630-220 |
630 |
630 |
220 |
1500/200 |
99.99 |
900 |
KEL720-760-150 |
720 |
760 |
150 |
1300/220 |
99.99 |
800 |
KEL820-600-150 |
820 |
600 |
150 |
1300/220 |
99.99 |
750 |
KEL610-610-150 |
610 |
610 |
150 |
1000/220 |
99.99 |
600 |
KEL484-484-220 |
484 |
484 |
220 |
1000/220 |
99.99 |
600 |
KEL600-600-150 |
600 |
600 |
150 |
1000/220 |
99.99 |
600 |
KEL305-610-150 |
305 |
610 |
150 |
500/220 |
99.99 |
400 |
KEL350-350-220 |
350 |
350 |
220 |
500/220 |
99.99 |
400 |
KEL320-320-220 |
320 |
320 |
220 |
400/220 |
99.99 |
350 |
