Class 1000 U Type Medical Stainless Steel Air Shower With SUS201 Nozzle

Certification
China KeLing Purification Technology Company certification
China KeLing Purification Technology Company certification
Customer Reviews
Keling had successfully supplied us following products on 25 Oct.2017 against PO NO.M170807; Their supplied Air Filters have been working satisfactorily since installation.We are satisfied with their products.

—— SIMPOR PHARMA

Since we do coopertae with them, they always offer good quality and keep the delivery on time to us, we do appreicated for their kind support !

—— Nasir

This is to certify that we bought U type air shower tunnel, Air Shower and HEPA filter, Secondary air filter ,perfilter for our project from KeLing Purification Technology Co. Ltd, 3C01 Tian Feng Commerce Square, Mid Building, No. 133, Baiyun AV, Baiyun Disctrict , Guangzhou , GuangDong, China against Contract No: 2014/4119005942 in October 22, 201

—— IATEC,Argentina

Product arrived faster than expected and they sent something special in addition to what I ordered. Nice people and fast service!

—— Mohammed Saad

I'm Online Chat Now

Class 1000 U Type Medical Stainless Steel Air Shower With SUS201 Nozzle

Class 1000 U Type Medical Stainless Steel Air Shower With SUS201 Nozzle
Class 1000 U Type Medical Stainless Steel Air Shower With SUS201 Nozzle Class 1000 U Type Medical Stainless Steel Air Shower With SUS201 Nozzle

Large Image :  Class 1000 U Type Medical Stainless Steel Air Shower With SUS201 Nozzle

Product Details:
Place of Origin: CHINA
Brand Name: K-LING
Certification: CE
Model Number: KEL-AS1400-P2
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: NEGOATION
Packaging Details: PLOWOOD PACKING
Delivery Time: 8 WORKING DAYS
Payment Terms: Ex works/FOB/CIF/ CNF
Supply Ability: 50UNITS/MONTH
Detailed Product Description
Other Name: Air Shower Room Type: U Type
Material: Whole SS304 Door: Singel Swing Door
Blowing Way: 3 Direction Blowing Control: PLC Control System
Locker: Electric Inter Locker Power: 380V/50HZ
High Light:

clean room equipment

,

air shower room





Class 1000 U Type Medical Stainless Steel Air Shower With SUS201 Nozzle





Quickly detail



External Size: 1400x2000x2180mm

Internal size: 1000x1930x1910mm

Single person with three side blowing

Purification rank: Class100

HEPA filter efficiency: 99.999%@0.3um

Personal per cycle: 1-6 person

SUS nozzle: 32pcs

Blower way : three side blowing

Air speed :>25m/s

Power: 380V/50HZ or 380V/50HZ





Introduction:



  Stainless steel Air Showers are designed to remove surface contamination from personnel
  prior to entering a Cleanroom or Clean Work Area such as a Paint Spray Booth.
  Numerous contaminants can be introduced into a clean room environment by being
  transported on the outer garments of an individual entering a clean room, and for
  that reason, many clean rooms will feature a personnel, equipment or product air shower
  cleanroom air shower is a self-contained unit that utilizes specialized, high efficiency
  air flow and other technologies to effectively remove all types of contaminants from
  the every individual.





Applications:



Pharmaceutical,Medical Device,Aerospace/Government,Health Care,Research Labs,Animal Labs,Precision Mfg.Metal Manufacture, Lead Industry,Electronics,Semiconductor



operating features :

  1: Special ultrathin blowing tube housing and fan, match with rotatable
       embedded stainless steel nozzle, greatly increased the space utilization
       and blowing tube effect
2: Built-in many sets of operating procedures, can be convenient and flexible
    call. Intelligent man-machine dialogue interface makes operation chain,
     such as real-time monitoring state.
3: Standard of the modular design, make field assembly faster and more
    convenient maintenance.
4: But according to user needs and site condition transformation function and form.





 Parameter :



KEL-AS1400-P2 Series

Model

KEL-AS1400-P2

External size(mm) (WXDXH)

1400x2000x2180

Work zone (mm)(WXDXH)

1000x1930x1910

Persons per cycle

2-4 person

Air shower Duration

                         Factory set at 12 second (adjustable)

Material

             Steel with white color epoxy power-coated or Stainless steel

Fan consumption

0.75KWX2 sets

Air flow of fan(m3/h)

                                                   1300m3/h

Fan run (r/min)

                                                    2800r/min

Nozzle in stain less steel

                                                     32pcs

Wind speed(m/s)

                                                      > 22-27m/s

Noise level(dB)

                                                      <62dB

LED Fluorescent Lamp

                                                                       20wx2





HEPA Filter

Size(mm)

                                            630X630X69mm

Efficiency

                                             99.99%@0.3um

Air velocity

                                               1000(m3/h)

Resistance

                                                 <220pa





Pre-filter

Size(mm)

                                                785x385x21

Efficiency

                                              75% @ 5um

Resistance

                                                   <30 Pa

Electrical

Power supply

                                                 380v/50Hz





































































Optional accessor


1.Manul swing door or automatic sliding door
2.HEPA air filter or ULPA air filter
3. The case is used of cold-rolled steel plate / all stainless steel air shower / just stainless steel inside
4. Common fluorescent lamp / UV Sterilizer lamp
5.  With voice announce



Factory test:



All of equipment is individually factory tested for safety and performance in accordance with international Standards. Each unit is shipped with a documentation outlining the tests undertaken and the units individual results for each unit.

Factory test include:

--functional test and visual inspection

--electrical safety tests

--air velocity testing

--purification rank test (if need)





Warranty:



Our equipment is warranty for 1 year excluding consumable parts and accessories.

All equipment is shipped with a comprehensive use’s manual complete with a report documenting all test procedures.

Additional IO/OQ/GMP document is available upon request.

Contact our sales representative for specific warranty details or document request.



Consumable parts illustration:



1: Pre-filter: each one should be replacement in each 6 month, but it can refresh no more three times.



2: HEPA filter: each one should be replacement in each half and one years.



Why you choose K-LING Company ?



1. Superior Quality

Quality is our biggest concern. We are always striving
for quality improvement from the first beginning.

2. Competitive Price

Competitive price is one of our advantages compared to
others. We are always working hard to lower down the cost
while still improve or keep the quality.

3. Customer first service

Focus on customization, we provide the free design by our
designers. Reply with 24 hours if any questions and pack
in time for delivery.

4. All-in-one convenience

We are dedicated to give you all-in-one service. You just
tell us your demand, then we will take care of your demand,
design drawings, build the clean room and provide you best after sale.


5. Product diversification

We are not only undertake clean room construction, clean
booth construction, etc., but also an agent to export
accessories from other factory. You could always choice the
 suitable products in our company.





Payment Term:



T/T in advance, 30% before place the order, 70% when you see copy BL

Or 30% T/T in advance before place the order, 70% LC at sight.
