KeLing Purification Technology Company Limited
-------------------------------------------------------------
Advanced. High-Qulity. Reasonable.
Sales & Support:
|
Product Details:
Payment & Shipping Terms:
|
| Efficiency: | H13 / H14 | Frame: | SUS 304 Frame |
|---|---|---|---|
| Filter Media: | Glassfiber Paper | Separator: | Yes |
| Size: | Customized | Max. Temperature: | 80°C |
| High Light: | H13 HEPA Air Filter,Glass Fiber HEPA Air Filter,Sus 304 Frame HEPA Air Filter |
||
How to produce
1 Raw materials: Natural cotton produced by ultra-fine glass fiber cotton production enterprises with large production scale and sound management system is selected as raw materials. The company uses advanced raw material testing and analysis equipment, and cooperates with reasonable and complete material inspection procedures. Ensure that all materials put into production meet the design requirements of the product.
2 The production line adopts advanced digital control module to realize the fine management of the whole process and avoid the operation error. Production line operation, process products real-time monitoring, to avoid the emergence of defective products
|
Grade |
Basic weight |
Thickness |
Pressure Drop |
Efficiency |
Tensile Strength (MD KN/M) |
Stiffness MD(mg) |
|
F6 |
70±2 |
0.45±0.06 |
≤ 15 |
≥15 |
≥1 |
≥1000 |
|
F7 |
70±2 |
0.45±0.06 |
≤ 30 |
≥50 |
≥1 |
≥1000 |
|
F8 |
70±2 |
0.45±0.06 |
≤ 45 |
≥60 |
≥1 |
≥1000 |
|
F9 |
70±2 |
0.45±0.06 |
≤ 70 |
≥85 |
≥1 |
≥1000 |
|
H10 |
72±2 |
0.4±0.06 |
≤ 127 |
≥92 |
≥1 |
≥1000 |
|
H11 |
75.87 |
0.4±0.06 |
≤ 180 |
≥98 |
≥1 |
≥1000 |
|
H12 |
75.98 |
0.4±0.06 |
≤ 250 |
≥99.8 |
≥1 |
≥1000 |
|
H13 |
76±2 |
0.4±0.03 |
≤ 280 |
≥99.977 |
≥1 |
≥1000 |
|
H14 |
76±2 |
0.4±0.03 |
≤ 372 |
≥99.998 |
≥1 |
≥1000 |
|
U15 |
76±2 |
0.4±0.03 |
≤ 440 |
≥99.9996 |
≥1 |
≥1000 |
OEM customized size is available
Structure description:
1. The filter material of international famous brand is selected to ensure the high efficiency of 99.99 % at 0.3um under the condition of fixed air volume.
2, temperature: 80 ℃, humidity: 100% RH (not fogging state).
3, can provide 120mm,150mm,220mm,290mm and other thickness.
4, can provide wood frame, galvanized iron frame, aluminum frame, stainless steel frame
5, the separator can provide aluminum partition and paper partition.
