| Efficiency: | H13 / H14 | Frame: | SUS 304 Frame |
|---|---|---|---|
| Filter Media: | Glassfiber Paper | Sealant: | Polyurethane |
| Size: | Customized | Max. Temperature: | 80°C |
| High Light: | HEPA Air Filter H10,High Humidity Resistant HEPA Air Filter,HEPA Air Filter H10 |
||
Product Introduction:
HEPA filter h13 is designed to arrest very fine dust effectively.
Hepa Filters are used in clean rooms,pharmathuticals,hospitals,labs,electronic workshop.semi-conductor places,air handling units,etc.
1)Height quality glass fiber paper
2)Glass fiber paper is folded into closely space shallow pleats, with textile thread spacers to ensure an optimal pleating geometry
3)Efficiency from 99.99%
Product features:
No partition design to reduce operating costs
Wide range of applications, compact structure, saving storage space
Ultra-thin design saves installation time
Material list:
Frame - anodized aluminum profiles
Optional thickness of frame - 50mm / 70mm / 90mm / 110mm
Filter material - ultra-fine fiberglass
Split line - hot melt adhesive
Sealant - polyurethane
Protective mesh - lacquered steel mesh
Efficiency:
99.99%@0.3μm (H13),99.999%@0.3μm (H14),99.9995%@0.12μm(H15),99.99995%@0.12μm(U16) (EN1822)
Specification And Technical Parameters
| Model |
Dimensions (mm) W×H×D |
Rated air flow m3/h |
Initial resistance pa |
Efficiency % |
Material | |||
| Media | Separator | Sealant | Frame | |||||
| HEK-HF |
305*305*150 305*610*150 610*610*150 762*610*150 915*610*150 305*305*292 305*610*292 610*610*292 |
300 500 1000 1200 1500 600 1000 2000 |
<220
|
>99.99 Sodium flame |
Fiberglass paper |
Aluminum foil; sized paper |
Polyurethane Rubber PU |
Galvanized steel Frame |
