| Blowing: | Two Side Blowing | Efficiency: | H13 |
|---|---|---|---|
| Application: | Pharmaceutical Industry | Standard: | GMP |
| Air Speed: | 25m/s | Original: | China |
| High Light: | 25m/S Air Speed Air Shower Tunnel,GMP Standard Air Shower Tunnel,H13 Efficiency air shower unit |
||
GMP Standard 25m/S Air Speed Air Shower Tunnel With High Efficiency Filters
Quicky Detail
External Size: 1400x3000x2200mm
Internal size: 800x2930x2000mm
Alternative type : one row person with 3 direction blowing
Purification rank: Class1000
HEPA filter efficiency: 99.999%@0.3um
Personal per cycle: 3-6 person
SUS nozzle: 44pcs
Blower way: three side nozzle
Air speed :>25m/s
Power: 380V/50HZ or 380V/60HZ, 415V/50ZH , 440V/50HZ
Applications:
Air shower tunnel can keep pharmaceutical, semiconductor, micro-electronics production and lab animal breeding areas clean and also minimize egress of hazardous substances and allergens from the controlled environment.
Air shower tunnel Parameter
| Quantity and specification | unit | remarks | ||
| Cabient | SUS304 stainless steel | |||
| Nozzles | 48-96 | pcs | ||
| Outlet air speed | ≥20 | m | ||
| Working time | 0—99 | S |
Adjustable
|
|
| Rated Voltage | 380 | V | 3 phase 4 wire | |
| Power | 2.25-10 KW | KW | 50Hz | |
| Hygienic standard | High efficiency | |||
| Noise | ≤65 | DB | ||
| External dimension | W*H 1700*2300 | Mm | ||
| Net size | W*H 800*1900 | Mm | ||
| Channel type | Seal type Tunnel type | |||
| Remarks |
Please inform us before the contract comes into effect.
|
|||
Air shower details photos
