| Name: | HEPA Air Filter | Frame: | Aluminum Frame |
|---|---|---|---|
| Filter Media: | Fiberglass | Sealant: | Polyurethane |
| Max. Humidity: | 80%RH | Max. Temperature: | 80°C |
| High Light: | Cleanroom HEPA Filters H13,aluminum frame Cleanroom HEPA Filters,Fiberglass H13 HEPA Air Filter |
||
Application: Final or return filtration for clean rooms
Type: HEPA filtering panel.
Frame: MDF Wood and anodised aluminium.
Gasket: as reqeust
Media: Glass fibre paper.
Separator: paper or aluminum
Sealant: Polyurethane.
Recommended final pressure drop: 600 Pa.
Temperature: 70°C maximum in continuous service.
Test: 100% individually scanned to EN 1822. system
Optional: Alternative frame materials and size available on request.
Top Gel Frame thickness :80mm,95mm,104mm
Side Gel Sealed Frame: 69mm,75mm,90mm,93mm, 96mm,100mm
Features:
-- low wind resistance,
-- high dust holding capacity,
-- high filtration precision,
-- processed into various sizes and shapes according to customer needs, and suitable for different models.
| Model NO. |
Size L*W*H (mm) |
Rated air flow (m³/h) |
Inital resistance (pa) |
Efficiency 0.3μm (flame method) |
| KEL | 320*320*220 | 400 | ≤220 | 99.99% |
| KEL | 484*484*220 | 1000 | ||
| KEL | 610*610*150 | 1000 | ||
| KEL | 630*630*220 | 1500 | ||
| KEL | 915*610*150 | 1500 | ||
| KEL | 595*595*290 | 2000 | ||
| KEL | 1220*610*150 | 2000 | ||
| KEL | 1260*630*220 | 3000 | ||
| KEL | 945*630*220 | 2200 | ||
| special size can be according to customer special requirement | ||||
