Product Details:
Payment & Shipping Terms:
|
| Material: | Stailess Steel SUS304/201/316 /galvanized Sheet | Size: | Customizable |
|---|---|---|---|
| Efficiency: | H14 | Noise: | 52dB |
| Pressure: | 97 Pa(10 Mm Aq) | Original: | GuangZhou China |
| High Light: | FFU Fan Filter Unit,52dB Fan Filter Unit,SUS304 ffu unit |
||
1) Wind speed: 0.2 - 0.5m/s
2) Noise: less than 60dB
3) Power: 220V, 50Hz
4) Highly efficient filter (filtration efficiency is 99.99%)
5) Material: armor plate
7) Adjustable speeds
8) Excellent performance
9) Using a highly-efficient centrifugal air blower
10) Durable, low noise, low vibration
11) Free maintenance
12) 2-year quality guarantee
13) Purification rank: class 100 in static state
Be used in the large air flow ventilation system,filtration system of pharmaceutical,food,hospital,clean room,etc.
It can be also used in terminal-filtration of mediun/hepa filtration system or pre-filtration of super-efficiency filtration system
| Model | FFU-1175 | FFU-1228 |
FFU-1178 |
FFU-578 | FFU-618 | |
|
Dimension (mm) |
575*1175*320 | 616*1228*320 | 578*1178*320 | 578*578*320 | 618*618*320 | |
|
air filter size (mm) |
570*1170*69 | 610*1220*69 | 570*1170*69 | 570*570*69 | 610*610*69 | |
|
air Volume (m³/h) |
700-1800 | 700-1900 | 700-1800 | 350-900 | 350-950 | |
|
External static pressure (Pa) |
98 | 98 | 98 | 98 | 98 | |
|
Main body
- |
Standard | cold rolled steel plate with powder coated | ||||
| Option |
Stainless steel Galvanized steel Aluminum coated zinc plate SUPER GALUM |
|||||
| Power supply | Standard | 220V 50Hz | ||||
| Option | Pls contact us if you have any other requirement about the power. | |||||
| Output poewr | 140-150 | |||||
|
Filter - |
Efficiency | HEPA Over 99.99% @ 0.3um | ||||
| ULPA Over 99.9995% @ 0.1um | ||||||
| Frame | Aluminum | |||||
|
Shock (m/s2) |
≤0.4 | ≤1.1 | ≤0.4 | |||
|
Noise Db(a) |
≤55 | ≤55 | ≤55 | |||
| Option | - | Differential draft gauge; Remote control; Duct flange for suction air; Pre-filter | ||||
