Auto Rolling Door 3 Sides Nozzle Modular Cleanroom Air Shower For Medical Industrial

Auto Rolling Door 3 Sides Nozzle Modular Cleanroom Air Shower For Medical Industrial
Auto Rolling Door 3 Sides Nozzle Modular Cleanroom Air Shower For Medical Industrial Auto Rolling Door 3 Sides Nozzle Modular Cleanroom Air Shower For Medical Industrial

Large Image :  Auto Rolling Door 3 Sides Nozzle Modular Cleanroom Air Shower For Medical Industrial

Product Details:
Place of Origin: CHINA
Brand Name: K-LING
Certification: CE
Model Number: KEL-ASP2500T-4 SERISE
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: NEGOATION
Packaging Details: PLOWOOD PACKING
Delivery Time: 15 WORKING DAYS AFTER DEPOSIT
Payment Terms: T/T, LC AT SIGHT
Supply Ability: 50UNITS/MONTH
Detailed Product Description
Name: Air Shower Tunnel /Channel Door: PVC Auto Roller Door
Control: PCB Control System Air Speed: More Than 24m/s
Fan: 0.75kw 380V/ 50HZ Nozzle: SUS Nozzle In 40 Pcs
Other Name: Medical Industrial Air Shower Room
High Light:

air shower system

,

electronics clean room

Auto Rolling Door 3 Sides Nozzle Modular Cleanroom Air Shower For Medical Industrial





Quicky detail



External Size: 2500x4000x2180mm

Internal size : 2000x3860x1910mm

Purification rank: Class10000

HEPA filter efficiency: 99.999%@0.3um

SUS nozzle: 88 pcs

Blower way: three side blower

Air speed :>25m/s

Power: 380V/50HZ





Description :



Air showers tunnel serve to protect your cleanroom environment from unwanted contamination.
Clean garments become contaminated during the gowning/ungowning process, general use, and
because of high traffic in the gowning area. The contamination problem is amplified when the
same garment is worn several times or is taken on and off numerous times during the day.

  The KEL-AS2500T series  air shower tunnel is a fast and effective method of removing this surface contamination,contamination that will otherwise be carried directly to your cleanroom and deposited on
your product and critically clean areas by sloughing off from the surface of the garments.
Air showers tunnel are available in a variety of sizes and shapes to provide a cleaning system to meet
your specific application.







operating features :





1 :  Microelectronics or PLC control system with LED display for the shower time.

2:  the air shower duration time adjustable from 0-99second.

3:  Infrared ray inductor for inside personal shower automatic from three side

4:  Human being voice remind of user progress in chamber.

5:  Emergency switch help you out of trouble, Comply with CE Test.

6:  Ion - static devices for the  electostatic charge neutralization.

7: Doors will close automatically when activated

8: Stainless steel nozzle on two sides, it's more effieciency to blow.

9: The air velocity is greater than 25m/s

10: Low noise level

11: Arc corner 100-rank static state, patented product
12: customized designe is available.



Parameter :





                                     KEL-AS2500T-4  Air Shower Tunnel

MODEL

KEL-AS2500T-4

External size (mm)

(WXDXH)

2500x4000x2180mm

Work zone (mm)

(WXDXH)

2000x3860x1910mm

Persons per cycle

   4 pallets goods

Air shower Duration

Factory set at 12 second (adjustable)

 Air shower direction

Three side with blowing

Material

(Option)

1: Entirety Sus304.

2: Entirety sus201.

3: External is steel with power coated, Internal is SUS304.

4: External is steel with power coated. Internal is SUS201.

Control system

1: PCL or microelectronics  comtrol system with LED display for

    the shower time. touchable screen display.

2: The shower time from 0-99second. (Adjustable).

3: Infrared ray inductor for inside personal shower automatic.

4: Human voice prompt system.

5: with CE remark.

The power of Fan

380V/50HZ/750W (2 set)

Air flow of fan(m3/h)

                 1300m3/h

Fan run (r/min)

                 2800r/min

Nozzle in stain less steel

                       88 pcs

Wind speed(m/s)

                      25-29m/s

Noise level(dB)

                       <62dB

LED Fluorescent Lamp

                         20wx4



HEPA Filter

Size(mm)

                         630X630X69mm

Efficiency

                       99.99%@0.3um

Air velocity

                   1000(m3/h)

Initial resistance(pa)

                    <220pa



Pre-filter

Size(mm)

                   775x380x17

Efficiency

                   75% @ 0.5um

Resistance(pa)

                      <30 Pa

Electrical

Power supply

                   380v/50Hz

   Net power(kw)

                  0.75X8 kw

Customer’s design is available.





Factory test:



All of equipment is individually factory tested for safety and performance

in accordance with international Standards. Each unit is shipped with a documentation outlining the tests undertaken and the units individual results for each unit.

Factory test include:

-- functional test and visual inspection

-- electrical safety tests

-- air velocity testing

-- purification rank test (if need)





Warranty:



Our equipment is warranty for 1 year excluding consumable parts and accessories.

All equipment is shipped with a comprehensive use’s manual complete with a report documenting all test procedures.

Additional IO/OQ/GMP document is available upon request.

Contact our sales representative for specific warranty details or document request.





Consumable parts illustration:



1: Pre-filter: each one should be replacement in each 6 month, but it can refresh no more three times.



2: HEPA filter: each one should be replacement in each half and one years.



Why you choose K-LING Company ?



Professional sales:

• We value every inquiry that you sent to us, ensure quick competitive offer.

• We cooperate with customer to bid tenders. Provide all necessory docuement.

• We are a sales team, with all techinical support from engineer team





Punctual delivery time:



• Production / inspection report provide before shipment

• Shipping notice or insurance for you when your goods is shipped.

After sales service:

• We respect your feed back after receive the goods.

• We provide one year warranty after goods arrive.

• We promise all spare parts available in lifetime use.

• We care of your complain within 48hours.





Payment Term:



 T/T in advance, 30% before place the order, 70% when you see copy BL

Or 30% T/T in advance before place the order, 70% LC at sight.
