Customized Tunnel Three Side Blowing Cleanroom Air Shower With Stainless Steel

Customized Tunnel Three Side Blowing Cleanroom Air Shower With Stainless Steel
Customized Tunnel Three Side Blowing Cleanroom Air Shower With Stainless Steel Customized Tunnel Three Side Blowing Cleanroom Air Shower With Stainless Steel

Large Image :  Customized Tunnel Three Side Blowing Cleanroom Air Shower With Stainless Steel

Product Details:
Place of Origin: CHINA
Brand Name: K-LING
Certification: CE
Model Number: KEL-ASP1300T-7Z SERISE
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: NEGOATION
Packaging Details: PLOWOOD PACKING
Delivery Time: 15 WORKING DAYS AFTER DEPOSIT
Payment Terms: T/T, LC AT SIGHT
Supply Ability: 50UNITS/MONTH
Detailed Product Description
Name: Air Shower Tunnel / Channel Contorl System: PCB Contorl Board
Fan: 6Sets Air Speed: More Than 23m/s
Purification Rank: Class 1000 Power: 380V/50HZ 0.75KW
Other Name: Three Side Blowing Air Shower Room
High Light:

air shower system

,

biological clean room

Customized Tunnel Three Side Blowing Cleanroom Air Shower With Stainless Steel





Quicky detail



External Size: 1300x7000x2180mm

Internal size :  790X6930X1910

HEPA filter efficiency: 99.999%@0.3um

Personal per cycle: 7-100 person

SUS nozzle:112 pcs

Blower way: three  side blowing

Air speed :>23m/s

Power: 380V/50HZ  415v/50HZ



Introduction:



Air shower tunnel not only plays an important role in supporting purification of personnel and things, air shower tunnel can remove personal or components' surface dust for the operating personnel to enter the clean work environment, but also plays the role of air brake to prevent not-yet-cleaned air from entering clean area as to ensure a clean local environment, further to ensure the reliability of the product running
environment and the rate of finished products with good results. it not only can use for beverage workshop but also can use for Semiconductor plant, microelectronics plant, bio-pharmaceutical plant, etc





operating features :



1 :  Microelelctrincs control system with LED display for the shower time.

2:  the air shower duration time adjustable from 0-99second.

3:  Infrared ray inductor for inside personal shower automatic from three side

4:  Human being voice remind of user progress in chamber.

5:  Emergency switch help you out of trouble, Comply with CE Test



                                  KEL-AS1300T-7Z  Air Shower Tunnel

MODEL

KEL-AS1300T-7Z

External size (mm)(WXDXH)

1300x7000x2180mm

Work zone (mm)(WXDXH)

790x6930x1910mm

Persons per cycle

   7-100 person

Air shower Duration

Factory set at 12 second (adjustable)

 Air shower direction

Three side with blowing

Material

(Option)

1: Entirety Sus304.

2: Entirety sus201.

3: External is steel with power coated, Internal is SUS304.

4: External is steel with power coated. Internal is SUS201.

Control system

1: PCL control system with LED display for the shower time.

2: The shower time from 0-99second. (Adjustable).

3: Infrared ray inductor for inside personal shower automatic.

4: Human voice prompt system.

5: with CE remark.

The power of Fan

380V/50HZ/750W

(7 sets)

Air flow of fan(m3/h)

    1300m3/h

Fan run (r/min)

2800r/min

Nozzle in stain less steel

   112 pcs

Wind speed(m/s)

   23-29m/s

Noise level(dB)

   <62dB

LED Fluorescent Lamp

20wx7



HEPA Filter

Size(mm)

630X630X96mm

Efficiency

99.99%@0.3um

Air velocity

1000(m3/h)

Initial resistance(pa)

   <220pa



Pre-filter

Size(mm)

    775x380x17

Efficiency

  75% @ 0.5um

Resistance(pa)

   <30 Pa

Electrical

Power supply

    380v/50Hz  415v/50HZ

   Net power(kw)

     0.75X7 kw

Customer’s design is available.





Factory test:



All of equipment is individually factory tested for safety and performance

in accordance with international Standards. Each unit is shipped with a documentation outlining the tests undertaken and the units individual results for each unit.

Factory test include:

-- functional test and visual inspection

-- electrical safety tests

-- air velocity testing

-- purification rank test (if need)





Warranty:



Our equipment is warranty for 1 year excluding consumable parts and accessories.

All equipment is shipped with a comprehensive use’s manual complete with a report documenting all test procedures.

Additional IO/OQ/GMP document is available upon request.

Contact our sales representative for specific warranty details or document request.





Consumable parts illustration:



1: Pre-filter: each one should be replacement in each 6 month, but it can refresh no more three times.



2: HEPA filter: each one should be replacement in each half and one years.



Why you choose K-LING Company ?



Professional sales:

• We value every inquiry that you sent to us, ensure quick competitive offer.

• We cooperate with customer to bid tenders. Provide all necessory docuement.

• We are a sales team, with all techinical support from engineer team





Punctual delivery time:



• Production / inspection report provide before shipment

• Shipping notice or insurance for you when your goods is shipped.

After sales service:

• We respect your feed back after receive the goods.

• We provide one year warranty after goods arrive.

• We promise all spare parts available in lifetime use.

• We care of your complain within 48hours.





Payment Term:



 T/T in advance, 30% before place the order, 70% when you see copy BL

Or 30% T/T in advance before place the order, 70% LC at sight.
