4 V Rigid Cell Lydall Fiberglass Air Filters Secondary Air Filter Replacement

4 V Rigid Cell Lydall Fiberglass Air Filters Secondary Air Filter Replacement
4 V Rigid Cell Lydall Fiberglass Air Filters Secondary Air Filter Replacement 4 V Rigid Cell Lydall Fiberglass Air Filters Secondary Air Filter Replacement

Large Image :  4 V Rigid Cell Lydall Fiberglass Air Filters Secondary Air Filter Replacement

Product Details:
Place of Origin: China
Brand Name: K-LING
Certification: EN799
Model Number: KEL-VC
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: NEGOATION
Packaging Details: PLOWOOD PACKING
Delivery Time: 8 working days
Payment Terms: Ex works/FOB/CIF/ CNF
Supply Ability: 2000Sets/month
Detailed Product Description
Size: 592X592X292mm Frame: ABS Plastic
Pack: 4V Media: Glass Fibre Media
Effiecency: F7-F9 Packing: Carton
Product Name: Rigid Cell Filter Application: HVAC System
Material: Galvanised Sheet Metal After-sales Service Provided: No Overseas Service Provided
High Light:

industrial air filters

,

home air filters

4 V Rigid Cell Lydall Fiberglass Air Filters Secondary Air Filter Replacement





Quickly detail



Media: Lydall glass fiber or PP media

Frame: Aluminum /Plastic

Filter efficiency: F5,F6.F7,F8,F9

Filter size: 592x592x292

Pack: 4 or 5 packs

Resistance:<30-50pa



4 V Rigid Cell Lydall Fiberglass Air Filters Secondary Air Filter Replacement 0

Performance:



Big media area, long time use life,  big air volume, low resistance, light weight and easy install .





Applications area:



4 V rigid Cell air filter widely use for medium filtration in industry and commercial field.

That is medium filter in clean room HVAC system.





Characteristics:



1: The 4 V rigid Cell air filter use for filter more than 0.5um particles and dust in HVAC air conditional system ,that particular design for HVAC project at low resistance with big air volume.

 2: The filter media adopt the pp media or ultra-thin glass fiber with high dust holding capacity , the hot-melt glue spacing each pleats in regular so that achieve high dust volume , all of the media area can be used in completely .

3: The polypropylene plastic frame can be Incineration when use out .

4: the filter with flange can replace by pocket air filter.

 The sealant around the media so that the air filter without any air leaking

5: the4 V rigid Cell air filterefficiency range: F6,F7, F8,F9(EN779).





Dimension and parameter:



Dimension

(W*H*D)

 (mm)

Pack

Air flow

(M3/h)

Media area

(m2)

Holding dust(g)

Primary resistance

(by0.5m/s)

Final

resistance

Efficiency

(0.3um)

287X287X292

 2

900

4.63

280

〈60

250-300

F6

〈80

300-400

F7

〈100

300-400

F8

〈120

400-450

F9

592X592X292

3

2850

15

900

〈60

250-300

F6

〈80

300-400

F7

〈100

300-400

F8

〈120

400-450

F9

592X592X292

4

3800

20

1200

〈60

250-300

F6

〈80

300-400

F7

〈100

300-400

F8

〈120

400-450

F9

592X490X292

4

3100

16.44

1000

〈60

250-300

F6

〈80

300-400

F7

〈100

300-400

F8

〈120

400-450

F9

592X287X292

4

1750

9.26

550

〈60

250-300

F6

〈80

300-400

F7

〈100

300-400

F8

〈120

400-450

F9

Customized size is available .





Material and operation conditions:



Media

  Glass fiber and PP media

Sealant

PU Sealant

Frame

Plastic /Galvanized/Aluminum/SUS frame

Media spacer

PU hot glue

Gasket

EVA, or Neoprene gasket

Efficiency

65-95% F6-F9

Max temperature

70°c

Max humidity

100%





Why you choose K-LING Company ?

Professional sales:

• We value every inquiry that you sent to us, ensure quick competitive offer.

• We cooperate with customer to bid tenders. Provide all necessory docuement.

• We are a sales team, with all techinical support from engineer team





Punctual delivery time:



• Production / inspection report provide before shipment

• Shipping notice or insurance for you when your goods is shipped.



After sales service:



• We respect your feed back after receive the goods.

• We provide one year warranty after goods arrive.

• We promise all spare parts available in lifetime use.

• We care of your complain within 48hours.





Payment Term:



 T/T in advance, 30% before place the order, 70% when you see copy BL

Or 30% T/T in advance before place the order, 70% LC at sight.
