HEPA Class 100 Clean Room Air Shower With Three Side Blower 380V / 50HZ

HEPA Class 100 Clean Room Air Shower With Three Side Blower 380V / 50HZ
HEPA Class 100 Clean Room Air Shower With Three Side Blower 380V / 50HZ HEPA Class 100 Clean Room Air Shower With Three Side Blower 380V / 50HZ HEPA Class 100 Clean Room Air Shower With Three Side Blower 380V / 50HZ

Large Image :  HEPA Class 100 Clean Room Air Shower With Three Side Blower 380V / 50HZ

Product Details:
Place of Origin: CHINA
Brand Name: K-LING
Certification: CE,
Model Number: KEL-AS1200T
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: NEGOTIATION
Packaging Details: POLYDOOD PACKING
Delivery Time: 8 WORKING DAYS
Payment Terms: Ex works/FOB/CIF/ CNF
Supply Ability: 50Set/month
Detailed Product Description
External Material: Steel With Power Coated Internal Material: 304 Staninless Steel
Control System: PCB Control System HEPA Air Filter: 610x610x69mm
HEPA Effeiency: H13 Perfilter: G3
Purification Rank: Class 100 Product Name: Clean Room Air Shower
High Light:

air shower system

,

electronics clean room



HEPA Air Shower Tunnel Class 100 Clean Room With Three Side Blower





Quicky detail



External Size: 1200x1500x2180mm

Internal size : 800x1430x1910mm

Purification rank: Class100

HEPA filter efficiency: 99.999%@0.3um

Personal per cycle: 2-50 person

SUS nozzle: 12-36pcs

Blower way: three size blower

Air speed :>25m/s

Power: 380V/50HZ





Introduction:



The greatest source of particulate contamination in a clean room is the operator air shower are installed between change areas and the clean room, the air shower enhances clean room operating protocol by serving as a reminder to all operators that they are entering a controlled environment, personnel should be gowning up properly before entering the air shower, after you pass the air shower

Applications: it can keep pharmaceutical, semiconductor, micro-electronics production and lab animal breeding areas clean and also minimize egress of hazardous substances and allergens from the controlled environment.





operating features :



1 :  Microelectronics control system with LED display for the shower time.

2: the air shower duration time adjustable from 0-99second.

3: Infrared ray inductor for inside personal shower automatic from three side

4: Human being voice remind of user progress in chamber.

5: Emergency switch help you out of trouble, Comply with CE Test

6: The door opening automatic when user hand induction at proper distance

                                    KEL-AS1200T  Air Shower Tunnel

MODEL

                          KEL-AS1200T - 1.5

External size (mm)

(WXDXH)

                           1200x1500x2180mm

Work zone (mm)

(WXDXH)

                               800x1430x1910mm

Persons per cycle

                                   2-4 person

Air shower Duration

                     Factory set at 12 second (adjustable)

 Air shower direction

                          Three side with blowing

Material

(Option)

1: Entirety Sus304.

2: Entirety sus201.

3: External is steel with power coated, Internal is SUS304.

4: External is steel with power coated. Internal is SUS201.

Control system

1: Microelectrics  control system with LED display for the shower time.

2: The shower time from 0-99second. (Adjustable).

3: Infrared ray inductor for inside personal shower automatic.

4: Human voice prompt system.

5: with CE remark.

The power of Fan

                                      380V/50HZ/750W

                                            (2 set)

Air flow of fan(m3/h)

                                         1300m3/h

Fan run (r/min)

                                          2800r/min

Nozzle in stain less steel

                                             22 pcs

Wind speed(m/s)

                                            23-29m/s

Noise level(dB)

                                            <62dB

LED Fluorescent Lamp

                                           20wx1



HEPA Filter

Size(mm)

                                   630X630X69mm

Efficiency

                                  99.99%@0.3um

Air velocity

                                        1000(m3/h)

Initial resistance(pa)

                                        <220pa



Pre-filter

Size(mm)

                                   775x380x17

Efficiency

                                75% @ 0.5um

Resistance(pa)

                                             <30 Pa

Electrical

Power supply

                                          380v/50Hz

   Net power(kw)

                                                 1.6 kw

Customer’s design is available.



Factory test:



All of equipment is individually factory tested for safety and performance in accordance with international Standards. Each unit is shipped with a documentation outlining the tests undertaken and the units individual results for each unit.

Factory test include:

-- functional test and visual inspection

-- electrical safety tests

-- air velocity testing

-- purification rank test (if need)





Warranty:



Our equipment is warranty for 1 year excluding consumable parts and accessories.

All equipment is shipped with a comprehensive use’s manual complete with a report documenting all test procedures.

Additional IO/OQ/GMP document is available upon request.

Contact our sales representative for specific warranty details or document request.



HEPA Class 100 Clean Room Air Shower With Three Side Blower 380V / 50HZ 0

Consumable parts illustration:



1: Pre-filter: each one should be replacement in each 6 month, but it can refresh no more three times.



2: HEPA filter: each one should be replacement in each half and one years.
