| Size: | Standard | Name: | Clean Room Air Shower |
|---|---|---|---|
| Other Name: | Air Shower Tunnel | Application: | Dust Free Area |
| Material: | Stainless Steel | Original: | China |
| High Light: | 1200Pa air shower clean room,stainless Steel SUS304 air shower room,H13 HEPA air shower room |
||
Standard Size Stainless Steel Clean Room Air Shower/ Air Shower Tunnel
Feature
Completely self-contained, pre-wired, fully equipped Air Shower/Tunnel systems help solve decontamination problems
Modular design lets you order a system to suit your cleanroom
HEPA filter/blower modules (rated 99.99% efficient @ 0.3 micron particles) wash personnel with Class 100 air to dislodge and remove particles
Solid-state microprocessor panel provides programmable control over access door operation.
Electromagnetic interlocking doors minimize contamination and automatically release in the event of power failure or when the emergency stop button is pressed
Energy-efficient LED lighting mounted on the ceiling
Available in white powder-coated or stainless steel to meet various cleanroom requirements
Variety of sizes and door configurations
Economical to operate and easy to maintain
An ionizing bar is available as an optional accessory
Clean Room Air Shower Quick Details:
1. Name: KEL-AS1300/P1 Stainless Steel Air Shower
2. Brand Name: anlaitech
3. Material: epoxy powder coated outside, stainless Steel SUS304 inside
4. Feature: LCD display control
5. Outside dimension: 1300×1000 ×2100 (mm)
Description:
Applicable: people
Materials: epoxy powder coated outside, stainless Steel SUS304 inside
Number of Nozzle: 24(Two Sides) Stainless Steel 304
Mouth Diameter of Nozzle: Φ30mm
Speed of Air Flow at the Nozzle: >25m/s
Dimension of High Efficiency Air Filter (mm): 600×600×120
Dimension of Air Shower Area (mm): 800×930×1960
Outside Dimension (mm): 1300×1000×2100
Lock: Electronic Interlock
Pre-Filter: 600*350*10(mm), 1PC, synthetic fiber with aluminum
HEPA Filter: 1PC, 600*600*120(mm)
FAN: 1PC, Power: 0.55KW, Air Volume:1500/PC, Air Pressure:1200Pa
LAMP: 2PCs, Power:20W
Shower Time: 0-99s adjustable
HEPA Filter Efficiency: H13,99.995%@0.38um.
Maximum Power Consumption: 1.1KW
Parameter
| Model | KEL-AS01 | HKEL-AS02 | KEL-AS03 | KEL-AS04 |
| External size(mm) | 1160*1000*2050 | 1290*1500*2050 | 1390*2000*2050 | 1390*2500*2050 |
| Internal size(mm) | 790*1000*1950 | 790*1000*1950 | 790*2000*1950 | 800*2500*1950 |
| Power supply | AC,1PH,220V 50/60HZ or AC, 3PH, 380V, 50/60HZ | |||
| Consumed power | 1100w | 1500w | 2200w | 2500W |
| No of nozzles | 12pcs | 18pcs | 24pcs | 48pcs |
| Air speed | 20-25m/s | |||
| Air shower time | 0-99s adjustable, standard is 10s | |||
| HEPA FILTER | H13 or H14, 99.99%@0.3um or 99.995%@0.3um | |||
| Material | SUS304, SUS201, baking finished optional | |||
|
NO. of person capacity |
1-2 | 2-3 | 3-4 | 4-6 |
| Remark | specification can be customized according to customer's requirement | |||
