| Media: | High Heat Resistant Glass Fiber Paper | Frame: | GI; Stainless Steel |
|---|---|---|---|
| Separator: | Aluminium Foil | Sealant: | Thermoresistant Sealant |
| Humidity Resistance: | 100% | Warranty: | 1 Year |
| High Light: | 500Pa HEPA Air Filter,Glass Fiber Paper HEPA Air Filter,350℃ hepa air purifier filter |
||
1. Waveness aluminum foil pleat or the paper pleat can make sure of the filtration material completely the thickness of the aluminum foil is 0.03mm the height of the waveness is 4mm,which make sure of the filtration area and the quality of the filter.
2. The filtration material is the high density paper which is made from super fine fiberglass, pleat the filtration paper (made from the fiberglass) in order to enlarge the filtration area as large as possible, and to slowdown the filtration speed. It is very important for the hepa filter.
3. Laser tested one by one, temperature resistance up to 80°C small resistance high efficiency ,long service life
1. Used for the high temperature cleanliness equipment or production line.
2. Production lines.
3. Applied to the terminal filtration for the air conditioning filtration system, used in hospital, electronic industry, food, precision instrument, electron semiconductors.
| Media | High Heat Resistant Glass fiber paper |
| Frame | GI; Stainless steel |
| Separator | Aluminium foil |
| Efficiency | 99.99@0.3μm Efficiency range from H13,H14 (EN 1822) |
| Initial resistance | 160 Pa |
| Sealant | Thermoresistant sealant |
| Recommended final pressure drop | 500Pa |
| Humidity resistance | 100% |
| Max Temperature | 250℃ or 350℃ |
| Max.air flow rate | 125% of rated air flow |
| Gasket | Red high heat resistant gasket. |
| Model | Nominal Size WxHxD (inch) | Actual Size WxHxD(mm) | Rated Airflow (m³/h) | Initial Resistance (pa) | Efficiency (Colorimetric Method) /Class |
| KEL | 19x19x8-2/3 | 484x484*220 | 1000 | ≤220 | ≥99.99% |
| KEL | 24 x 24 x 5-7/8 | 610x610x150 | 1000 | ||
| KEL | 36 x 24 x 5-7/8 | 915x610x150 | 1500 | ||
| KEL | 24 x 24 x 11-3/5 | 610x610x290 | 1900 |
