PVC Curtain Door Dynamic Softwall Cleanroom For Medical Equipment

China PVC Curtain Door Dynamic Softwall Cleanroom For Medical Equipment supplier
PVC Curtain Door Dynamic Softwall Cleanroom For Medical Equipment supplier PVC Curtain Door Dynamic Softwall Cleanroom For Medical Equipment supplier

Large Image :  PVC Curtain Door Dynamic Softwall Cleanroom For Medical Equipment

Product Details:

Place of Origin: CHINA
Brand Name: K-LING
Certification: CE
Model Number: KEL-LFB5000

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Plywood packing
Delivery Time: 7-15 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 sets per month
Contact Now
Detailed Product Description
Color: KEL Specification: According Customer's Requirement
Origin: GuangZhou Certificate: CE
Warranty: 1 Year Treadmark: KEL

PVC Curtain Door Dynamic Soft Wall Clean Room For Medical Equipment





Introduction


1.Clean Booth is also called non-dust working room. It is the fastest and most convenient simply equipped clean room. It has multi-kinds of classification and space collocations, can be designed as per customers' request. The main feature of it is short construction time and good mobility. In addition, for partial area that require high cleanness, we can add additional high level filters thus to de crease the costs.
2.The main structure consists of the stainless steel square pipe and aluminum alloy square pipe. Air flow is provided by fan filter unit FFU, anti-static curtain around, covered the seal blind in the top to reach a sealed zone, the inside cleanliness class will be ISO Class 4~8 / FS209E Class 10~100000; it is very suitable in the high cleanliness requirements of the workshop zone, e.g. assembly line work zone, high precision products assembling zone.
3.The fan inhale the air from the top of FFU, the air changes to clean air after going through the primary filter and high efficiency filter and was sent out to the clean booth with the constant speed of 0.45m/s±20%, thus forming an even laminar flow and making the clean air flow form a vertical unidirectional flow, effectively ensure the cleanliness of the working zone.





Advantages


1. Modularity, compositional design, convenient installation, easy to improve the cleanliness, strong expandability and recyclable, it is applied to improve the cleanliness of clean zone.
2. Can be installed the omni-directional wheel, moving flexible, it is a simple purifying instrument.
3. Interior used space is larger than the non-dust working platform; less expensive, fast construction, loose requirement of floor compared with the traditional non-dust room.
4. It can be used single, also can used with the other equipment.





Parameter



Parameter Softwall Clean Booth(PVC) Hardwall Clean Booth(Toughened glass,color steel panel)
Cleanliness From Class 100 to Class 100,000
External Dimension As per requirement
FFU Dimension 2*2/2*4/4*4
Cabinet Material Galvanized frame
Power source 110V/60hz/av/dc, 220V/60HZ/AV/DC
HEPA Filter H14 Hepa filter
Frame Material Stainless Steel/ aluminume profile/ powder coated steel
Wall Material Anti-static soft PVC wall 106~109Ω plastic curtain
Lighting Lamps Available in LED and T5
Air condition As per requirement Available in constant temperature air conditioner/constant temperature and humidity conditioner
Class Level Model Inner dimension Number of Air volume(m3/h)
W * D * H (mm) FFU
Class100 KEL-LFB2000A 2000 * 3000 * 2200 6 6600
KEL-LFB2440A 2440 * 3660 * 2200 12 13200
KEL-LFB2450A 2450 * 4880 * 2200 16 17600
KEL-LFB2440A 2440 * 6100 * 2200 20 22000
Class 1000 KEL-LFB2000B 2000 * 3000 * 2200 2 2200
KEL-LFB2440B 2440 * 4880 * 2200 4 4400
KEL-LFB3660B 3660 * 4880 * 2200 6 6600
KEL-LFB6100B 6100 * 7300 * 2200 12 13200
Class 10000 KEL-LFB2000C 2000 * 3000 * 2200 1 1100
KEL-LFB2440C 2440 * 4880 * 2200 2 2200
KEL-LFB3660C 3660 * 4880 * 2200 4 4400
KEL-LFB6100C 6100 * 7300 * 2200 8 8800



Customer's design is avaliable!
