Multi - Function Softwall Clean Room With PC Control System / Plastic Curtain Wall

Multi - Function Softwall Clean Room With PC Control System  /  Plastic Curtain Wall
Multi - Function Softwall Clean Room With PC Control System  /  Plastic Curtain Wall Multi - Function Softwall Clean Room With PC Control System  /  Plastic Curtain Wall

Large Image :  Multi - Function Softwall Clean Room With PC Control System / Plastic Curtain Wall

Product Details:
Place of Origin: China
Brand Name: K-LING
Certification: CE,
Model Number: KEL-LFB5000
Payment & Shipping Terms:
Minimum Order Quantity: 1SQM
Price: NEGOATION
Packaging Details: PLOWOOD PACKING
Delivery Time: 8 WORKING DAYS
Payment Terms: Ex works/FOB/CIF/ CNF
Supply Ability: 2000sqm/month
Detailed Product Description
Product Name: ISO7 Modular Cleanroom Purification Rank: Class 100-class 10000
Frame: Steel With Powder Coated Tube Wall: Plastic Curtain
Ceiling: Steel With Powder Caoted Board Fan Filter Unit: 175x575x350mm
Hepa Filter: 99.99%@0.3um Perfilter: G1-G2
After-sales Service Provided: Engineer Available To Service Machiner Oversea Application: OT Room, Air Clening In A Small Area
Product Name: Class 10000 Clean Room Waranty: 1 Year
High Light:

Laboratory clean room

,

portable clean room

K-Ling Customized Modular Clean Room Design For ISO7 Modular Cleanroom



Softwall  Modular clean room introduction:





Clean Room Modular is a kind of clean room, it can quickly improve the cleanliness of the equipment. Because of its low cost, convenient and flexible asembly, it is widely used in optical, electronic assembly line work, laboratories, assembly area local area purify occasions. The clean booth adopt to FFU generating winds, with industrialize aluminum(stainless steel or painting steel) as it's frame and static-free sticker(or carbon glass), it can make the clean room's cleanliness attain 10-100K.



Parameter:



Customer's design is available!

MODEL KEL-LFB2000 KEL-LFB3000 KEL-LFB4000 KEL-LFB5000
Ex size (mm)(W*D*H) 2000X2000X2596 3000X3000X2596 4000X4000X2596 5000X5000X2596
In size (mm) 1900x1900x2205 2900x2900x2205 3900x3900x2205 4900x4900x2205
Purification rank Class10-300,000(FS209E USA)
HEPA filter Efficiency : 99.99% @ 0.3um - 99.999% @ 0.12um (MPPS)
Pre-filter Efficiency : 85% @ 5um
Control system PC control system / promised speed by control box
Pressure Gauge American Dywer pressure
Noise <50-55 dB (test point distance is 1m)
Air velocity(m3/h) 0.2-0.5m/s Adjustable (test point distance is 30cm)
Frame material stainless steel/steel with power coated/Cast aluminum profile
Wall frame Tempered glass / PVC anti-static curtain (option)
Fan EBM Fan /Taiwan fan/ Domestic fan (option)
Power suppler AC110/220v 50HZ/60HZ



Multi - Function Softwall Clean Room With PC Control System  /  Plastic Curtain Wall 0



Feature:


Flexible Assembly: Compared to the tradtitional clean booth it is easy to installation, cost effective with less investment and quick return, as it cost shorter construction period in the assembling frame by manufacturer.
Selected High Quality Material: import for the grind curtain and adjustable plastiv cup and universal wheel, convenience for installation and maintance.
Humanized Structure: Compared to the clean bench it has the multi-function, which can be used as a unit or combined with another clean equipment together. Even you can assemble it on the production line to change dust-free production.
Flexibility: Less limitation or low requirements for the floor and spot situation, the iner space is enough to use and the frame canbe recycled

Multi - Function Softwall Clean Room With PC Control System  /  Plastic Curtain Wall 1
