Payment & Shipping Terms:
|Air Speed:||25-30m3/h||Locker:||Electric Interlocker|
|Door:||Single Swing Door||Effieincy:||firstname.lastname@example.org|
|Product Name:||Cleanroom Air Shower Tunnel||HEPA Filter:||H13 HEPA Filter|
ISO8 Class Clean Room Air Showers Tunnel With H13 HEPA Filter
Model number : KEL-AS1400V Series
Material: inside and outside is stainless steel304 (t=1.0mm)
OEM /ODM: Yes
Certificated: CE and Rosh
Start port: Guangzhou
Delivery time: 8 working days after we get the deposit.
Country of Original: China
Supply ability: 50 set/one month
Payment term: T/T , L/C , Western union ,
Application: Worker in Clean room
Vertical air flow in top side
External Material: stainless steel304 (t=1.0) Or steel with milk color power coated
Inside Material: stainless steel304 (t=1.0)
External size: 1400*1000*2180mm Internal size: 790*930*1910mm
Sus nozzle: 16pcs
Blowing way: one side (top)
Air speed: more than 25m/s
Door: Electric Interlocking in both side.
Laboratory Decontamination Air Shower Working Principle:
Fresh air was forced by the blower(s) through HEPA filter(s) which are 99.99% efficient against particles of 0.3 microns.
Filtered air is ejected through nozzles at high velocities . These turbulent air streams disperse particulate matter on all surfaces.
Dispersed particulate matter migrate with the air stream towards the lower areas in the air shower.
Air enters the blower supply plenum through pre-filter(s) installed at the base of the air shower.
The air is continuously filtered and recirculated.
The air shower is a selfcontained device and does not exchange air with the environment it is placed in.
Laboratory Air Showers & Tunnels:
|Dimensions mm; see diagram above||
No. of Filters/
|Epoxy powder||Shipping Weight(KG)|
|Double blow air shower, epoxy powder-coated steel made, stainless steel 304 base and door|
1:Own factory with competitive price
2: Automatic production line.
3:Nearly 10 years experience in cleanroom industry.
4:We are an expert in providing customized solutions.
5:Timely delivery with perfect quality.
6:Fortune 500 companies’ choice.
7:Have passed ISO9001.2008 certification.
Factory testing (all the sets you ordered):
All of equipment is individually factory tested for safety and performance in accordance with international Standards. Each unit is shipped with a documentation outlining the tests undertaken and the unit’s individual results for each unit.
Factory test include:
--functional test and visual inspection
--electrical safety tests
--air velocity testing
Our equipment is warranty for 1 year excluding consumable parts and accessories.
All equipment is shipped with a comprehensive use’s manual complete with a report documenting all test procedures.
Additional IO/OQ/GMP document is available upon request.
Contact our sales representative for specific warranty details or document request.
