Payment & Shipping Terms:
|Product Name:||Dispensing Booth, Clean Booth, Dispensing/Sampling Booth, Filtering Syetem, Weighing Room||HEPA Filter:||firstname.lastname@example.org|
|Air Velocity:||0.2-0.6 M/s (adjustable)||Power:||380 V/ 50 HZ|
Manufacturers Directly Sell SUS 304 Dispensing Booth For Purification Rank 100
Dispensing booth is a special studio specializing in sampling, weighing, analysis and other industries. It can control the dust in the working area from spreading out of the operation area, ensuring that the operator does not inhale the items being operated. It is a special purification equipment for controlling dust flying. The indoor air passes through the primary filter and the medium efficiency filter, and is pressed into the static pressure box by the centrifugal fan. After passing through the high efficiency filter, the air is blown out from the air outlet surface of the airflow diffusing air supply unit, and the clean air flows through the working area at a uniform cross section wind speed. To form a high clean working environment. The operating area of the center dispensing booth is maintained at a negative pressure state, discharging 10% of the circulating air. The air in the dispensing booth is self-circulating through a three-stage filtration system (high-efficiency filter removes 99.99% of all dust above 0.3 μm).
Product design drawing
This is a dispensing booth drawing with an inner dimension of 1900 x 1700 x 200 mm and an outer dimension of 2000 x 2000 x 2500 mm. We can design dispensing booth drawings according to your needs.
External size (mm)
Work zone (mm)
|Purification rank||Class 100(ISO5)|
1: Entirety Stainless Steel 201/304/316.(T=1.2/1.5mm)
2: External and internal side is steel with power coated. (T=1.2/1.5mm)
1: Air Speed according to frequency converter control .
2: Gel Sealant High Efficiency HEPA air filter for high purification rank
3: Wind speed detection, Constant temperature and constant humidity
Detector according to client request install
4: DOP/PAO Port and differential Pressure Guage for HEPA /secondary filter so that remind of you change the air filter in time
5: 5 different filter configuration available utilizing combination of G4,F8.H13,H14 and PLF Screens .
6; GMP Modular design with minimized joints and seams.
7: PVC strip curtains available
8; Energy Efficient high air volume fan to minimize operating cost,
|Filter step||3 Step|
|HEPA filter||99.995% @ 0.3um Gel sealant mini--pleats HEPA Air Filter|
|Secondary filter||F8 pocket air filter|
|Power supply||380V/50HZ OR 220V/50HZ|
|Packing material||Standard Export Poly wood Packing(Fumigant free material)|
Customer's design is available.
KeLing Purification Technology Co., Ltd engaged in air purification filed for many years.It ia s Professional team for research and development clean room products whose sale air purification clean room equipments and clean room HVAC air filters. This is the construction picture of dispensing booth for our customers.
