G4 Pleats Type Cardboard Frame Primary Air Filter For Air Conditioning System

China G4 Pleats Type Cardboard Frame Primary Air Filter For Air Conditioning System supplier
G4 Pleats Type Cardboard Frame Primary Air Filter For Air Conditioning System supplier G4 Pleats Type Cardboard Frame Primary Air Filter For Air Conditioning System supplier G4 Pleats Type Cardboard Frame Primary Air Filter For Air Conditioning System supplier G4 Pleats Type Cardboard Frame Primary Air Filter For Air Conditioning System supplier

Large Image :  G4 Pleats Type Cardboard Frame Primary Air Filter For Air Conditioning System

Product Details:

Place of Origin: CHINA
Brand Name: K - LING
Certification: CE , RoHS
Model Number: KEL - CP

Payment & Shipping Terms:

Minimum Order Quantity: 100pcs
Price: Negotiation
Packaging Details: Carton Packing
Delivery Time: 7 - 10 Working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1000pcs / month
Contact Now
Detailed Product Description
Name: Cardboard Frame Primary Air Filter Efficiency: G4
Dimension: 592X592X46mm Media Area: 0.94 ㎡
Dust Holding: 188g Initial Resisitance: <45pa
Finally Resistance: 150-250

G4 Pleats Type Cardboard Frame Primary Air Filter For Air Conditioning System



Introduction :



Carboard frame primary air filter is a disposable filter , because of its low resistance , large dust capacity and low cost , it is widely used in the primary air filter . It is mainly made of synthetic fiber material , which has good filtering effect and meets the filtering requirements . The main purpose of using air filter is to make air clean up to standard . The principle is to capture and absorb dust particles of different particle sizes in the air , so as to improve the air quality and purify the air .





Application :

1.  Central air conditioning fresh air unit and ventilation system .

2.  Pre - filtration system of high efficiency filters .

3.  Pre - filtration of centralized ventilation systems widely used in office buildings, shopping malls, hospitals, airports and general industrial buildings or clean rooms .



Features :



1.  G4 cardboard frame primary air filter is suitable for primary filtration of air conditioning system or pre - filtration of centralized ventilation air conditioning system .

2.  The outer paper frame is made of waterproof and moistureproof cardboard . It has high strength and is not easy to deform .

3.  Initial filter of the carboard frame air filter uses synthetic fiber filter material . The folded structure of filter material can fully increase the filter area and increase its dust capacity. reduce the resistance of the filter, thus prolonging the service life of the filter. The dust particles flowing into the air are effectively blocked by the filter material , and the clean air flows out uniformly from the other side .

4.  Small resistance, large dust capacity and low cost .





Photographs :

G4 Pleats Type Cardboard Frame Primary Air Filter For Air Conditioning SystemG4 Pleats Type Cardboard Frame Primary Air Filter For Air Conditioning SystemG4 Pleats Type Cardboard Frame Primary Air Filter For Air Conditioning System



Parameters :





Cardboard Frame Primary Air Filter

Dimension

(mm)

592x592x46 592x490x46 592x287x46 490x592x46 490x490x46

Air Flow

(m3/h)

2545 2110 1245 2106 1746
Media Area(㎡) 0.94 0.78 0.46 0.78 0.65
Dust Holding(g) 188 156 92 156 129

Initial Resistance

(pa)

<45 <45 <45 <45 <45

Finally Resistance

(pa)

150-250 150-250 150-250 150-250 150-250
Efficiency G4
