Customizable PVC Fast Rolling Door Air Shower Tunnel For Class 1000 Clean Room

China Customizable PVC Fast Rolling Door Air Shower Tunnel For Class 1000 Clean Room supplier
Customizable PVC Fast Rolling Door Air Shower Tunnel For Class 1000 Clean Room supplier Customizable PVC Fast Rolling Door Air Shower Tunnel For Class 1000 Clean Room supplier Customizable PVC Fast Rolling Door Air Shower Tunnel For Class 1000 Clean Room supplier

Large Image :  Customizable PVC Fast Rolling Door Air Shower Tunnel For Class 1000 Clean Room

Product Details:

Place of Origin: CHINA
Brand Name: K-LING
Certification: CE
Model Number: KEL-ASP1300T SERIES

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: NEGOTIATION
Packaging Details: PLYWOOD PACKING
Delivery Time: 15 WORKING DAYS AFTER DEPOSIT
Payment Terms: L/C, T/T, Western Union
Supply Ability: 50 UNITS/MONTH
Contact Now
Detailed Product Description
Noise: <62dB Fan Run: 2800 R/ Min
Electrical Power: 380 V / 50 HZ Wind Speed: > 25 M/s
Opening Speed: 0.8-1.5 M/s(adjustable) Closing Speed: >0.6 M/s (adjustable)

Introduction



Fast rolling door air shower is based on the ordinary air shower to change the door system, using PVC material to make up the door that can roll up and down. Fast rolling door air shower can be used in many scenarios, such as food, medicine, health care products, materials, chemistry, electronics, printing, assembly, precision machinery workshop and logistics, warehousing, air shower room, cargo shower room, welding room, etc. It can meet the needs of frequent logistics and clean places, and has the advantages of saving energy, increasing air conditioning effect, fast automatic shutdown, improving operation efficiency and creating a comfortable working environment.

Customizable PVC Fast Rolling Door Air Shower Tunnel For Class 1000 Clean Room



Product arameters



KEL-AS1300T Air shower Tunnel
Model KEL-AS1300T-7.2 KEL-AS1300T-7.3
External size(mm) (WXDXH) 1150x1030x2180mm 1150×2030×2180mm
Work zone 790x960x1910mm 790×1960×1919mm
(mm)(WXDXH)
Persons per cycle 1-2 person 2-4 person
Air shower Duration Factory set at 12 second (adjustable)
Material 1: Entirety Sus304.(T=1.0/1.2mm)
2:External is steel with power coated,
Internal is SUS304.(T=1.0/1.2mm)
3: External is steel with power coated.
Internal is SUS201. (T=1.0/1.2mm)
Fan consumption 0.75KWX1 set 0.75KW×2 set
Air flow of fan(m3/h) 1300m3/h
Fan run (r/min) 2800r/min
Nozzle in stain less steel 12pcs 24pcs
Wind speed(m/s) > 22-27m/s
Noise level(dB) <62dB
LED Fluorescent Lamp 20wx1 20w×2
  Efficiency 99.99%@0.3um
HEPA Filter Air velocity 1000(m3/h)
  Resistance <220pa
  Efficiency 75% @ 5um
Pre-filter Resistance <30 Pa
Electrical Power supply 380v/50Hz OR 380v/60Hz
Customer’s design is available





Product Design Drawings

Customizable PVC Fast Rolling Door Air Shower Tunnel For Class 1000 Clean Room

1.fast shutter motor             2.air shower control board                3.SUS Nozzle                 4.infrared sensor

5A/B: sensor for door open           6.PVC rolling door                   7.big air volume motor    8.HEPA air filter

9.Pre-filter                          10A/B: sensor for door close              11.purification light





Control system



Enter the clean room:



When sensor 5A senses person or cargo, the entrance door opens automatically.

Persons or goods enter the sensing area of sensor 4

When sensor 4 senses person or cargo, and sensor 10 and sensor 5A do not sense person or cargo, the entrance door closes.

After the two doors are closed, the air shower starts and begins to blow. The time is set to 15 s. Users can adjust the time according to their needs.

When the blow stops, the exit door opens.

When sensor 4, sensor 10B and sensor 5B senses no one or cargo, the exit door closes.



Get out of the clean room:



When person or cargo station is in the sensing area of sensor 5B, the exit door opens.

Persons or goods enter sensor 4 sensing area

When the sensor 4 senses someone or goods, while the sensor 5B and 10B do not, the exit door closes.

Both doors will be closed, and after three seconds, the entrance door opens. When the inductor 4, 5A and 10A cannot sense people or goods, the entrance door closes.



Case Presentation

Customizable PVC Fast Rolling Door Air Shower Tunnel For Class 1000 Clean Room

Construction Site Drawings



Customizable PVC Fast Rolling Door Air Shower Tunnel For Class 1000 Clean Room
