Professional Custom Vertical Laminar Air Flow Clean Cabinet Class 100
Vertical Laminar Air Flow Clean Carbinet is a kind of clean air equipment that provides local clean an sterile working environment , which can make the working area meet the requirement of 100% purification . Comparing with building clean rooms , this equipment reduces cost in initial investment and operating cost and create a favorable environment for improving the production quality and yield .
Electronics , Semi - conductors, Medicine and Health , Biological pharmaceuticals , Aerospace , Aseptic laboratory , Scientific research , Food , Hard-disk manufactory , Precise instrument , Opto - electronics
Operation Features :
1. The air moves downward from filter positioned in the ceiling toward the working area .
2. Vertical Laminar Clean Air Flow cabinet offers the benefits of vertical airflow around objects on the work surface and horizontal outflow through the work access opening acting as a barrier against contamination .
3. The work surface on each vertical laminar air flow clean carbinet is constructed from stainless steel for easy cleaning and decontamination .
4. Wind velocity can be adjusted with optional wind velocity controller .
5. The design of glass on the two side windows and no front sash ensure a bright and spacious working area .
6. Easily and flexibly moving with high quality casters and conveniently and reliably fixation with support legs .
7. High efficiency and high cleanliness .
8. Low noise , easy operation .
1: Pre - filter , 2: Centrigugal blower , 3: Pressure gauge , 4; Mini-pleats Hepa filter , 5:Control panel , 6; Fluorescent lamp , 7； Toughhened glass , 8; Socket , 9: Working table ( SUS ) , 10: Removable wheel , 11； Support leg
|Vertical Laminar Air Flow Clean Cabinet
||KEL - VCB1
||KEL - VCB2
||KEL - VCB3
( W * D * H ) mm
( W * D * H ) mm
||Class 100 ( FS209E )
|Rating Air Flow
||950m3 / h
||1100m3 / h
||1400m3 / h
- Cabinet is steel with power coated and working area is SUS304 / 201 .
- Cabinet and working area is SUS 304 / 201 .
||More than 99.99 % @ 0.3um H13 - H14
||0.3 - 0.6m/s ( Three levels are adjustable )
||American Dwyer Pressure Watch 1pcs
||20W * 1pcs
||30W * 1pcs
||40W * 1pcs
||220V - 240V 50 / 60HZ
Available Selection :
1. Extra Doplex Outlets
2. Safety Glass Hood
