Super Specialty OT Laminar Flow Ceiling For Hospital Operation Cleanroom
CUSTOMIZED DESIGN IS AVAILABLE
Description:
It with highest filter efficiency up to 99.9999% for 0.12um particles filtration, with the special design which specialized for hospital operation clean room ceiling can combine with operation special lights.
Laminar flow ceiling comply with Biological contamination control system that can prevent the dust, particle, bacterial from the operating room, creating the high purification rank,
appropriate temperature and humidity so that we have comfortable clean and safe environment.
In accordance with the purification class, laminar flow air supply ceiling is divided into Class
5/6/7/ 8 /9 (ISO14644-1) laminar flow air supply ceiling, or classified to burn ward, blood ward and ophthalmic operating room laminar flow air supply ceiling, etc.
Cold rolled steel with power coated and stainless steel materials can be selected by customers.
The T type special aluminum configured with spring clip-on installation makes the maintenance and installation convenient and time-saving.
The DPP equalizer net makes the air more uniform and gentle. The medium speed airflow compensation device is optional.
The high efficiency air filter can be decorated to two kinds of air supply, side air supply and roof air supply.
The non-standard dimension of laminar flow air supply ceiling can be made in case of special actual environment.
Application: Operating room
Technical Parameter :
| Model | KEL-LFC1 | KEL-LFC2 | KEL-LFC3 |
|
Cabinet size(mm) (L*W*D) |
2680X2840X500 | 2680X1880X500 | 2680X1480X500 |
|
Laminar flow size (mm) |
2600X2400 | 2600X1800 | 2600X1400 |
| Flange size( mm) | 500X200 (4PCS) | 500X200 (4PCS) | 320X200 (4PCS) |
| Efficiency | 99.99%@0.3um-99.999%0.12um(MPPS) | ||
| Air velocity(m3/h) | 0.45 | 0.3 | 0.23 |
| Using occasion | ⅰClass operate room | ⅱClass operate room |
ⅲ Class operate room
|
Basic Info:
| Product Name | laminar flow ceiling/laminar Panels |
| Brand | OEM/ODM |
| Material | SUS304,SUS201,SS304 |
| Size | Customized |
| MOQ | 1 SET |
| Delivery Time | 7-15 working days |
| Shipping Port | Guangzhou, Shenzhen, Shanghai |
| Warranty | 2 years |
| Packing | Polywood packing |
| Payment | T/T,L/C, West Union, D/P, Cash |
Hospital Operation Clean room laminar flow ceiling Characteristic:
This laminar flow ceiling compose of the HEPA Fltration unit and centrifugal ventilator, according to air-resistance leaking technology make the air stream dispersed evenly ensure the operate room in high purification rank ,
that widely use for the hospital clean operate room, clean sickroom, clean animal room and so on.
