|Name:||Powder Downflow Booths||Material:||Cold-rolled Plate, Ss304|
|Airflow Velocity:||0.2-0.6 M/S||Filters:||G4,F8.H13,H14 And PLF Screens|
|Start Port:||Guangzhou, Shenzhen, Shanghai||Warranty:||2 Years|
Cleanroom Equipment SUS304 Negative Pressure Laminar Flow Powder Downflow Booths
CUSTOMIZED DESIGN IS AVAILABLE
Clean booth is a kind of air purifying equipment providing partial high clean environment,
it’s the easiest and fastest way to build a simple clean room. Equipped with a lot of clean level and space collocation,
it can be designed as request. Main characteristics: simple use, good flexibility, easy installation, short construction time, and movable.
It can be installed in part of clean room of general level which requires high cleanliness to save cost.
Negative Pressure Laminar Flow
GMP Modular design with minimized joints and seams.
5 different filters configuration available utilizing combination of G4,F8.H13,H14
and PLF Screens .
Gel sealant HEPA Air Filter(firstname.lastname@example.org) for high purification rank
Purification rank: Class100 /ISO5
Air speed: 0.45m/s+_20%
10% Exhaust air leaking (Adjustable)
Cleanroom sampling /weighing/dispensing booth is mainly used in pharmaceutical clean room,electronic clean room,
hospital operating room,food clean room for weighing and dispensing of medicines,fine dust or reagent.
It can control dust flying or reagent overflowing to prevent operators from inhalling,and avoid cross-contamination of different materials and protect environment and operators.
External size (mm)
Work zone (mm)
|Purification rank||Class 100(ISO5)|
|Air speed||0.45m/s +_20%|
1: Entirety Stainless Steel 201/304/316.(T=1.2/1.5mm)
2: External and internal side is steel with power coated. (T=1.2/1.5mm)
1: Air Speed according to frequency converter control .
2: Gel Sealant High Efficiency HEPA air filter for high purification rank
3: Wind speed detection, Constant temperature and constant humidity
Detector according to client request install
4: DOP/PAO Port and differential Pressure Guage for HEPA /secondary filter so that remind of you change the air filter in time
5: 5 different filter configuration available utilizing combination of G4,F8.H13,H14 and PLF Screens .
6; GMP Modular design with minimized joints and seams.
7: PVC strip curtains available
8; Energy Efficient high air volume fan to minimize operating cost,
|Filter step||3 Step|
|HEPA filter||99.995% @ 0.3um Gel sealant mini--pleats HEPA Air Filter|
|Secondary filter||F8 pocket air filter|
|Pre-filter Efficiency||G4 Z-Line panel air filter|
|Power supply||380V/50HZ OR 220V/50HZ|
|Packing material||Standard Export Poly wood Packing(Fumigant free material)|
