Shockproof Air Shower Clean Transfer Window

Shockproof Air Shower Clean Transfer Window
Shockproof Air Shower Clean Transfer Window Shockproof Air Shower Clean Transfer Window Shockproof Air Shower Clean Transfer Window Shockproof Air Shower Clean Transfer Window

Large Image :  Shockproof Air Shower Clean Transfer Window

Product Details:
Place of Origin: China
Brand Name: Haoairtech
Certification: CE
Model Number: HA-DPB750
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Detailed Product Description
Brand: Haoairtech Material: 1: Entirety Sus304.(T=1.2/1.5mm) 2: Entirety Sus201.(T=1.2/1.5mm) 3: External Is Steel With Power Coated, Internal Is SUS304(T=1.2/1.5mm) 4: External Is Steel With Power Coated. Internal Is SUS201(T=1.2/1.5mm)
MODEL: HA-DPB750 External Size (mm) (W*D*H): 910x750x840mm
Work Zone (mm) (W*D*H): 750x750x750mm Purification Rank: Class 100
UV Light: 1 Piece
High Light:

clean room pass through box

,

Pass Thru Box

Laboratory Air Shower Clean Transfer Window/ Pass Box With Best Price stainless steel material



Introduction:



1. Stainless steel 304, completely shockproof and very un-reactive to other chemicals
2. Can be installed wind shower, optional interphone, mechanical interlock, electronic interlock.
3. UV light to enhance protection
4. Static, semi active and active pass boxes available
5. OEM, ODM acceptable
6. CE certificate




Working Principle Of Pass Box



1. Mechanical interlocking device: The internal interlocking is realized in the form of a machine. When one door is opened, the other door cannot be opened. The other door must be closed before the other door can be opened.



2. Electronic interlocking device: The internal use of integrated circuits, electromagnetic locks, control panels, lights and other interlocking, when one of the doors is open, the other door open indicator light is off, to inform this door can not be opened, while electromagnetic Lock action to achieve interlocking. When the door is closed, the other electromagnetic lock starts to work and the indicator lights up, indicating that the other door can be opened.



Products Parameter:

MODEL HA-DPB750
External size (mm)
(W*D*H)
910x750x840mm
Work zone (mm)
(W*D*H)
750x750x750mm
Purification rank Class 100
Material
(Option)
1: Entirety Sus304.(T=1.2/1.5mm)
2: Entirety Sus201.(T=1.2/1.5mm)
3: External is steel with power coated, Internal is SUS304(T=1.2/1.5mm)
4: External is steel with power coated. Internal is SUS201(T=1.2/1.5mm)
Control system 1: Gel Sealant mini-pleats HEPA air filter so that pass the DOP test without any problem.
2: Pass Box inside bottom corner is round shape without any dust
accumulation .
3: Double layer vacuum glass have very good appearance
4: Software computer interlocking door with long time using life
5: Air speed is 0.45m/s adjustable
UV light 1 PCS
Power supply 220v/50HZ
Packing material Standard Export Poly wood Packing(Fumigant free material)





Pass Box Outlook:

pass box4



pass box a  (1)

pass box6



Q&A

Q:How long is the lead time?

A:10 working days.

Q:Can we buy a sample door as trial order first?
A:Of course.You can buy a sample door with a reasonable price.

Q:How about your after sale service?
A:We will reply you within 24 hours by email or phone or video.

Q:How long is the warranty time?
A:1 year since you receive the product.

Q:Why choose your products?
A:Not only for the lower-price,but also higher-quality.
